Analog Devices EVAL-AD9888EB Quick Start Manual page 4

EVAL-AD9888EB
Table 1. Sample Settings for the EVAL-AD9888EB
Mode Resolution
VGA 640 × 480 @ 60 Hz
640 × 480 @ 72 Hz
640 × 480 @ 75 Hz
640 × 480 @ 85 Hz
SVGA 800 × 600 @ 56 Hz
800 × 600 @ 60 Hz
800 × 600 @ 72 Hz
800 × 600 @ 75 Hz
800 × 600 @ 85 Hz
XGA 1024 × 768 @ 60 Hz
1024 × 768 @ 70 Hz
1024 × 768 @ 75 Hz
1024 × 768 @ 80 Hz
1024 × 768 @ 85 Hz
SXGA 1280 × 1024 @ 60 Hz
1280 × 1024 @ 75 Hz
1280 × 1024 @ 85 Hz
UXGA 1280 × 1024 @ 60 Hz
1280 × 1024 @ 65 Hz
1280 × 1024 @ 70 Hz
1280 × 1024 @ 75 Hz
1
PLL divisor to the chip should be an odd integer; Chip divide ratio = Input N + offset of 1.
2
The VCO range and charge pump current settings are preliminary and may need slight adjustments.
ESD CAUTION
ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily accumulate on the
human body and test equipment and can discharge without detection. Although this product features
proprietary ESD protection circuitry, permanent damage may occur on devices subjected to high energy
electrostatic discharges. Therefore, proper ESD precautions are recommended to avoid performance
degradation or loss of functionality.
