Setup Overview - ST STM32 Quick Start Manual

• 1x Bluetooth Low Energy Expansion Board (X-NUCLEO-
BNRG2A1)
• 1x Motion MEMS and Environmental Sensor Expansion Board
(X-NUCLEO-IKS01A2 or X-NUCLEO-IKS01A3)
• 1x STM32 Nucleo Development Board (NUCLEO-F401RE or
NUCLEO-L476RG or NUCLEO-L053R8)
• 1x Android™ or iOS™ device
• 1x PC with Windows 7 and above
• 1x USB type A to Mini-B USB cable
For optimizing the performances of the SPBTLE-RF module
present on X-NUCLEO-IDB05A1 expansion board, it is necessary
to follow this sequence of boards stack
NUCLEO-F401RE
NUCLEO-L476RG
NUCLEO-L053R8
X-NUCLEO-IKS01A2
Mini USB

Setup Overview

HW prerequisites
X-NUCLEO-BNRG2A1
X-NUCLEO-IKS01A3
14
