6 Specifications
6.5 Data Processing Unit Software: ICPEsolution

6.5.1 Measurement Samples

1 data file, 300 samples max.

6.5.2 Qualitative Analysis

Analysis using internal database
Automatic selection of qualitative-analysis wavelength for each sample
Database correction function
6.5.3 Quantitative Analysis: Calibration Curve Method / Standard Addition Method
Measurement wavelength:
Possible to set multiple measurement wavelengths for each element
Automatic selection of quantitative-analysis wavelength for each sample
Correction methods:
Background correction, inter-element correction, internal standard correction, drift correction,
weight/dilution correction
Calibration curve:
1st to 3rd order expressions
Printing:
Setting of printing items
Automatic printing of analysis results after measurement
Batch printing (analysis conditions, calibration curves, analysis results, etc.)
Saving data:
Echelle mode (all data saved)
Analysis wavelength save mode (only data for selected wavelengths saved)
Recalculation functions:
Addition and recalculation for analysis elements and wavelengths
Recalculation of intensity after changing intensity calculation information, such as the
accumulation interval, the background point, or the internal standard element
Changing of calibration curve conditions, such as the calibration curve order
QA/QC functions (optional):
Evaluation and recorrection of calibration curve and inter-element correction coefficients
Evaluation, recorrection, and remeasurement of drift during measurement
Recovery test, dilution test, remeasurement test
Copying of display contents:
Analysis values, profiles, and calibration curves can be copied to other applications using the
Windows clipboard function.
6 - 2
