  • Page 1 UseR MANUAl ANGY MADE ITALY design & production 004281159 - Rev.000...
  • Page 2 APPLY TECHNICAL DATA LABEL ENGLISH...
  • Page 3: Table Of Contents

    attENtIoN SurfacES caN BEcoME vEry Hot! aLWayS uSE protEctIvE GLovES! During combustion, thermal energy is released that significantly increases the heat of surfaces, doors, handles, controls, glass, exhaust pipes, and even the front of the appliance. Avoid contact with those elements if not wearing protective clothing (protective gloves included).
  • Page 4: English

    We thank you for having chosen our company; our product is a great heating solution developed from the most advanced technology with top quality machining and modern design, aimed at making you enjoy the fantastic sensation that the heat of a flame gives, in complete safety. Warnings This instructions manual is an integral part of the product: make sure that it always accompanies the appliance, even if transferred to another owner...
  • Page 5 RECEIVED INSTRUCTIONS ON SAFE USE OF THE APPLIANCE AND THAT THEY UNDERSTAND THE INHERENT DANGERS. Š THE GENERATOR MUST NOT BE USED BY PERSONS (INCLUDING CHILDREN) WITH REDUCED PHYSICAL, SENSORY AND MENTAL CAPACITIES OR WHO ARE UNSKILLED PERSONS, UNLESS THEY ARE SUPERVISED AND TRAINED REGARDING USE OF THE APPLIANCE BY A PERSON RESPONSIBLE FOR THEIR SAFETY.
  • Page 6: Routine Maintenance

    (STRONG WIND, FREEzING) SAFETY SYSTEMS MAY INTERVENE THAT SWITCH THE GENERATOR OFF. IF THIS OCCURS, CONTACT THE TECHNICAL AFTER-SALES SERVICE AND ALWAYS DISABLE THE SAFETY SYSTEMS. Š IN THE EVENT THE FLUE CATCHES FIRE, USE SUITABLE SYSTEMS FOR SUFFOCATING THE FLAMES OR REQUEST HELP FROM THE FIRE BRIGADE.
  • Page 7: Installation

    InstallatIOn general The flue gas exhaust and hydraulic connections must be carried out by qualified personnel who must issue installation conformity documentation compliant with national standards. The installer must provide the owner or person acting for him, according to the legislation in force, with the declaration of conformity, supplied with: 1) the use and maintenance manual of the appliance and of the system components (such as for example, the smoke ducts, chimney, etc.);...
  • Page 8 In the presence of type B gas appliances with intermittent operation not intended for heating, they must have their own aeration and/or ventilation opening. The air inlets must meet the following requirements: Š they must be protected with grids, metal mesh, etc., but without reducing the net useful section; Š...
  • Page 9: Hermetically Sealed Installation

    Hermetically sealed installation The generator is a fully sealed product with respect to the environment in which it is installed. This means that it is ideal for passive houses because it does not take air in from within the house. combustion air To ensure the stove remains hermetically sealed, the connection pipe for the combustion air must be directly connected to the exterior, using special pipes and sealed connectors.
  • Page 10: Details Of Angie

    DEtAIls oF ANGIE Access to combustion chamber Rear fumes exhaust On/Off and ash drawer Pellet hopper pressurised closure fuse Serial input Room air outlet 230V power supply Supplementary thermostat input Radio/emergency board Combustion air inlet ENGLISH...
  • Page 11: Stove Positioning

    stovE posItIoNING for best performance, it is recommended to position the stove in such a way that it is perfectly level, with the aid of a spirit level. NotE For CorrECt FuNCtIoNING Pellet hopper lid The following indications must be respected for correct pellet stove functioning: Both during the functioning and when the stove is not in use, all the machine doors (pellet hopper, fire door, ash drawer) must...
  • Page 12: Upper Fumes Outlet Assembly

    UPPER FUMES OUTLET ASSEMBLY THE CONVERSION OF THE REAR FLUE gAS OUTLET MUST BE CARRIED OUT BY QUALIFIED PERSONNEL AND/OR THE MANUFACTURER’S TECHNICIANS FOLLOW THE ASSEMBLY INSTRUCTIONS CAREFULLY! ALWAYS FOLLOW THE ASSEMBLY INSTRUCTIONS IN COMPLETE SAFETY! THE STOVE MUST BE COMPLETELY COLD, SWITCHED OFF AND DISCONNECTED FROM THE ELECTRICAL POWER SUPPLY. NOT AVAILABLE It Is forbIdden to carry out thIs assembly and Install the applIance wIth the upper flue gas outlet for all uses throughout metropolItan france and Its overseas departments and regIons (drom),...
  • Page 13: Pellets And Loading

    Pellets and loading Pellets are made by subjecting wood shavings i.e. the rejects of pure unpainted wood from sawmills, carpentry products and products from other activities connected to wood working and transformation, to very high pressures. This type of fuel is fully ecological as no glues are used for its compaction. In fact, pellet compactness is guaranteed over time by a natural substance found in wood: lignin.
  • Page 14: Radio/Emergency Card

    Radio/emeRgency caRd The stove is fitted with an emergency radio card which allows for basic control of the stove in the event of a fault or if the remote control is malfunctioning. The functions that can be managed from the emergency card are: On/Off stove.
  • Page 15: Radio Control

    radIO cOntrOl cOnFIGUratIOn RADIO CONTROl DEvICE CODINg PROCEDURE: 1. Disconnect the power supply to the stove. 2. Press the keys at the same time until the RADIO ID channel page appears 3. Using the buttons select the new RADIO ID channel (it is possible to select a RADIO ID channel between 0 and 63). 4.
  • Page 16: Radio Control Device Features

    radIO cOntrOl deVIce FeatUreS Š The radio control is fitted with an lCD backlit display. The display remains lit for 5 seconds. After a certain period of time, in order to minimise battery consumption, the display turns off (sleep mode). Š...
  • Page 17: Display

    dISplay ScREEn in oPERation STAND BY active Chrono active Battery low Power 1-5^ Time Temperature detected in room Tangential fan active Room SET THERMOSTAT set Display text Tangential fan active in QUIET mode ScREEn WitH EXtERnaL tHERMoStat connEctED to tHE tERMinaL “ta” Time Indicates the status of the contact of the external...
  • Page 18: General Menu

    General menU Function Function Scroll through parameters Back - exit key Modify settings Ignition - switch-off key Access menu key MoDE VEntiLation EaSy SEtuP cHRono EnaBLinG cHRono MoDE PRG1 PRG2 SEttinGS DatE-tiME PRG3 LanGuaGE PRG4 DiSPLay StanD By DELta-t FiRSt LoaD * StoVE StatuS DEGREES RESEt...
  • Page 19: First Ignition Settings

    FIrSt IGnItIOn SettInGS After connecting the power cord at the back of the generator, turn the switch (if any) to position (I). The switch is used to power the heat generator board. date/tIme This menu allows the date and time to be set. To set: OK >...
  • Page 20: Operation And Logic

    OperatIOn and lOGIc IGnItIOn Once the previously listed points have been checked, press key for three seconds to ignite the stove. During ignition, the stove will check for a flame for a period of 15 minutes. Once the control temperature has been reached, the stove interrupts the ignition phase and switches to PREPARATION.
  • Page 21: Modes

    mOdeS This menu is used to set the operating logic of the machine for the power used. Range: (MANUAl, AUTOMATIC, AUX) By selecting MANUAl mode, the user can choose the heat output level delivered and the type of vENTIlATION, according to his/her preferences.
  • Page 22: Chrono

    cHrOnO This function allows stove ignition and switch-off to be automatically programmed. The factory setting for CHRONO is off. The chrono allows the programming of 4 time slots per day, which can be used every day of the week. In each time slot, it is possible to set the ignition and switch-off times, the days of use of the programmed time slot, the desired temperature (if aUtOmatIc mode is used) and the set power.
  • Page 23: Example

    eXample cHrOnO tIme SlOt 02:00 08:00 16:30 23:00 manUal 02:00 08:00 16:30 23:00 Power Start 02:00 Time slot 1 Power 5 Stop 23:00 02:00 08:00 16:30 23:00 Start 08:00 Time slot 2 Power 1 02:00 08:00 16:30 23:00 Stop 16:30 22°...
  • Page 24: Settings

    SettInGS Š DATE/TIME Š lANgUAgE SEE CHAPTER: COMMISSIONINg SETTINgS. Š DEgREES dISplay The “DISPlAY" menu allows: Š Adjustment of Display contrast. Š Activation/Deactivation of backlight. Š Enabling/disabling of acoustic signal. Š Setting of the timer to turn off the Display backlight. Š...
  • Page 25: Delta-T

    The entire Wi-Fi interface is grouped under the Settings -> W-Fi menu The configuration must be made using the Total Control 3.0 App, which can be downloaded from Play Store or Apple Store. https://www.lanordica-extraflame.com Š RESEt The setting allows you to reset the Wi-Fi to factory settings To set: OK >...
  • Page 26: Operation And Solutions

    The RADIO PROBE is an optional accessory that controls the temperature in the installation or ducting room without having to use wired sensors. For further details on its use and features, go to the website https://www.lanordica-extraflame.com/it depreSSUre nOtIce It allows you to activate the buzzer for acoustic warnings if the door or the hopper are open.
  • Page 27: Additional Functions

    addItIOnal FUnctIOnS addItIOnal tHermOStat InStallatIOn (OptIOnal) The stove can control the room temperature through an additional thermostat (optional). After ignition (by pressing key 1 or in chrono mode), the stove will work to reach the set value on the thermostat, displaying WORK (closed contact) on the screen.
  • Page 28: Cleaning And Maintenance

    TO FIND OUT WHERE YOUR NEAREST SERVICE CENTRE IS, CONTACT YOUR DEALER OR GO TO THE WEBSITE: WWW.LANORDICA-EXTRAFLAME.COM Cleaning and maintenanCe always follow the instruCtions with maximum safety! Š Make sure that the power cord is unplugged because the generator may have been programmed to switch on.
  • Page 29 every 3 days burn Pot and Combustion Chamber: Š Extract any residue in the burn pot Š Completely remove the burn pot from the relevant compartment; Š Extract the ash from the burn pot housing, ignition plug holder tube and combustion chamber.
  • Page 30: Routine Maintenance Performed By Qualified Technicians

    TO FIND OUT WHERE YOUR NEAREST SERVICE CENTRE IS, CONTACT YOUR DEALER OR GO TO THE WEBSITE: WWW.LANORDICA-EXTRAFLAME.COM routine maintenanCe Performed by Qualified teChniCians routine maintenance must be performed at least once a year. Given the generator uses pellets as solid fuel, it requires annual routine maintenance, which must be performed by a Qualified technician, using only original spare parts.
  • Page 31 TO FIND OUT WHERE YOUR NEAREST SERVICE CENTRE IS, CONTACT YOUR DEALER OR GO TO THE WEBSITE: WWW.LANORDICA-EXTRAFLAME.COM THE IMAGES ARE FOR ILLUSTRATIVE PURPOSES. Fumes motor (disassembly and cleaning and fumes and "T" pipes), new silicone in the specified points...
  • Page 32 TO FIND OUT WHERE YOUR NEAREST SERVICE CENTRE IS, CONTACT YOUR DEALER OR GO TO THE WEBSITE: WWW.LANORDICA-EXTRAFLAME.COM THE IMAGES ARE FOR ILLUSTRATIVE PURPOSES. Fumes motor (disassembly and cleaning and fumes and "T" pipes), new silicone in the specified points...
  • Page 33: Displays

    Displays Display Reason Generator off sTaRT The start-up phase is in progress pelleT loaDinG Continuous pellet loading is in progress during the ignition phase iGniTion The ignition phase is in progress pRepaRaTion The preparation phase is in progress WoRk The normal work phase is in progress MoDulaTion The generator is working at minimum final cleaninG...
  • Page 34 Differential pressure transducer faulty or Differential pressure transducer faulty or **DelTa-p faulT DelTa-p faulT Contact after-sales centre Contact after-sales centre disconnected. disconnected. The ash drawer is not closed correctly. The ash drawer is not closed correctly. Check hermetic closure of the ash drawer. Check hermetic closure of the ash drawer.
  • Page 35: Disposal

    Disposal InformatIon for management of electrIc and electronIc applIance waste contaInIng batterIes or accumulators This symbol, which is used on the product, batteries, accumulators or on the packaging or documents, means that at the end of its useful life, this product, the batteries and the accumulators included must not be collected, recycled or disposed of together with domestic waste. Improper management of electric or electronic waste or batteries or accumulators can lead to the leakage of hazardous substances contained in the product.
  • Page 36 ExtraflamE S.p.a. Via Dell’Artigianato, 12 36030 - MONTECCHIO PRECALCINO (VI) - ITALY   +39.0445.865911 -  +39.0445.865912 -  info@extraflame.it - www.lanordica-extraflame.com MADE ITALY design & production TO FIND THE SERVICE CENTRE NEAREST TO YOU CONTACT YOUR DEALER OR CONSULT THE SITE WWW.LANORDICA-EXTRAFLAME.COM...
