- Page 1 Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per La Nordica Anastasia Plus o cerca il tuo prodotto tra le migliori offerte di Stufe, Camini e Riscaldamento pellet stoves useR Manual anastasia plus MADE ITALY design & production...
- Page 2 ENGLISH...
-
Page 3: Table Of Contents
SafEty ..........................................4 routINE MaINtENaNcE ....................................5 INStaLLatIoN ........................................6 General ..................................................6 PELLEtS aNd fEEdING ....................................8 dEtaILS of aNaStaSIa PLuS ..................................9 radio/emerGency Board ..........................................9 rearminG ..................................................9 ductING fEaturES ...................................... 10 factory dEfauLt ductING oPEratIoN ..............................10 ductING oPEratIoN WItH tHErMoStat or ProBE (oPtIoNaL) ....................... -
Page 4: English
We thank you for having chosen our company; our product is a great heating solution developed from the most advanced technology with top quality machining and modern design, aimed at making you enjoy the fantastic sensation that the heat of a flame gives, in complete safety. Warnings This instructions manual is an integral part of the product: make sure that it always accompanies the appliance, even if transferred to another owner or user, or if transferred to another place. -
Page 5: Routine Maintenance
Š DO NOT LEAVE THE PACKAGING ELEMENTS WITHIN REACH OF CHILDREN OR UNASSISTED DISABLED PERSONS. Š THE HEARTH DOOR MUST ALWAYS BE CLOSED DURING NORMAL FUNCTIONING OF THE PRODUCT. Š WHEN THE APPLIANCE IS FUNCTIONING AND HOT TO THE TOUCH, ESPECIALLY ALL EXTERNAL SURFACES, ATTENTION MUST BE PAID Š... -
Page 6: Installation
InstallatIon general The flue gas exhaust and hydraulic connections must be carried out by qualified personnel who must issue installation conformity documentation compliant with national standards. the installer must provide the owner or person acting for him, according to the legislation in force, with the declaration of conformity, supplied with: 1) the use and maintenance manual of the appliance and of the system components (such as for example, the smoke ducts, chimney, etc.);... - Page 7 In the presence of type B gas appliances with intermittent operation not intended for heating, they must have their own aeration and/or ventilation opening. The air inlets must meet the following requirements: Š they must be protected with grids, metal mesh, etc., but without reducing the net useful section; Š...
-
Page 8: Pellets And Feeding
Pellets and feeding Pellets are made by applying high pressure to sawdust, or wood waste products (not containing paint) from sawmills, carpentry and other activities related to processing and working with wood. Given that it does not use any glue to hold it together this type of fuel is completely environmentally friendly. -
Page 9: Details Of Anastasia Plus
Details of anastasia plus Radio/emergency board Flue gas exhaust Combustive air input Z1 ducting Serial input On/OFF Z2 ducting ReaRming External thermostat connection Power supply and fuse RaDio/emeRgency BoaRD The stove is fitted with an emergency radio board located in the rear part, allowing the basic operation of the stove in the event the handheld device is damaged or malfunctions. -
Page 10: Ducting Features
Ducting featuRes The AnASTASIA PLUS model is fitted with two independent ducting outlets. Ducts Z1 - Z2 are activated by default. Features: Š diameter of ducting outlet: 2x80 mm Š maximum recommended ducting length 8m Š temperature controlled ducting Š regulation of air flow speed as a percentage Š... -
Page 11: Ta Supplementary Thermostat (Optional)
with pRoBe (ntC 10K) Remove the bridge on Z1 and attach the ntC probe in the room where you wish to control the temperature through Z1 ducting. two operating modes: Z1 moDe set to "on": • Until the desired temperature is reached the ducting motor will follow the stove settings. Set the desired temperature on the set •... -
Page 12: Handheld
handheld cOnFIGUratIOn HAndHeld codIng procedure: 1. disconnect the power supply to the stove. 2. press keys at the same time until the unIT selection screen appears. 3. using keys select the new unIT. 4. power the stove. confirm the selected unit within 10 seconds (all leds flash on the radio/emergency card) by pressing the oK key on the handheld. -
Page 13: Handheld Features
handheld FeatUreS The handheld is fitted with an lcd backlit display. The display remains lit for 5 seconds. After a certain period of time, in order to minimise battery consumption, the display turns off (sleep mode). It turns on again after pressing the on/oFF key (6). caUtIOn! do not place the handheld in direct or indirect contact with water. -
Page 14: Display
dISplay STAnd-BY AcTIve cHrono Z1 - Z2 AcTIve Z1 Z2 STBY 10:50 TIme °C TemperATure deTecTed comForT AcTIve In room loW BATTerY room TemperATure In reQueST 10:50 IndIcATeS conTAcT oF eXTernAl SupplemenTArY THermoSTAT 10:50 AlArm/error preSenT ALL DEPR (no IgnITIon) IdenTIFIcATIon oF AlArm/error ENGLISH... -
Page 15: General Menu
General menU FUnCTiOn FUnCTiOn Scroll parameters Back - exit key modify settings on - off key menu access key uSer menu % pelleTS % v1 FAn reSeT SeT cHrono enABle cHrono SeT prg1 SeT prg2 SeT prg3 ducTIng Z1 mode SeT prg4 SeT Zone Z1 Z1 FAn %... -
Page 16: Commissioning Settings
cOmmISSIOnInG SettInGS once the power cable at the back of the generator has been connected, move the switch, also located on the back, to (I). The switch at the back of the generator powers the generator board. The generator remains off and a first screen appears on the panel reading oFF. lIne FreqUency 50/ 60hz If the generator is installed in a country with a frequency of 60Hz, the generator will display "incorrect line frequency". -
Page 17: Operation And Logic
OperatIOn and lOGIc IGnItIOn once the previously listed points have been checked, press key for three seconds to ignite the stove. 15 minutes are available for the ignition phase. After ignition and after reaching the control temperature, the stove interrupts the ignition phase and switches to STArT-up. StartInG during the start-up phase, the stove stabilises combustion, increasing it progressively, to then start ventilation and switch to WorK. -
Page 18: User Menu
USer menU uSer menu % pelleTS v1 FAn reSeT pelletS The following menu allows the regulation of the pellet feed percentage. If the stove presents operational problems due to the quantity of pellets, pellet feeding can be regulated directly from the control board. problems linked to the quantity of fuel can be divided into 2 categories: no Fuel: Š... -
Page 19: Set Chrono
Set chrOnO SeT cHrono enABle cHrono SeT prg1 SeT prg2 SeT prg3 SeT prg4 This function allows the generator's ignition and switch-off to be automatically programmed. By factory default, the SeT cHrono is disabled. The chrono allows the programming of 4 time slots within a day, which can be used every day of the week. Ignition and switch-off times can be set for each time slot, along with the specific days of application for the programmed time slot and the desired temperature. -
Page 20: Ducting
dUctInG The menu allows the stove's ducting Z1 and Z2 to be controlled. For details on how ducting works, see chapter:" ducting operation with thermostat or probe (optional)" dUctInG Z1 mode on/oFF/eco Z1 ducTIng operATIon mode Select SeT Zone Z1 oFF- 07 - 40°c Z1 Zone TemperATure enable set... -
Page 21: Display
dISplay The "dISplAY" menu allows: Š regulation of display contrast Š Activation/deactivation of backlight. Š enabling/disabling of acoustic signal. Š Set the timer to turn off the display backlight. Š Set the timer to turn off the display (sleep mode). SettInGS xx:xx - dd/mm/yy SeT clocK... -
Page 22: Delta T
delta t This function allows the hysteresis to be configured for stove switch-off delTa T off ( set temperature + delta T oFF hysteresis) and for stove ignition (set temperature + delta T on hysteresis) if it is not managed by an external thermostat. The delta T On/OFF range is: OFF - 0.5 - 5.5°C SettInGS xx:xx - dd/mm/yy... -
Page 23: Cleaning And Maintenance
cLeanIng anD MaIntenance aLwaYS foLLow the InStructIonS In MaxIMuM SafetY conDItIonS! Š Make sue the power cable is unplugged since the generator could be programmed to start. Š That the generator is cold in its entirety. Š The ashes are completely cold. Š... - Page 24 Open the door - Clean the glass with a damp cloth Never spray the detergent or any other liquid used for cleaning directly on the ceramic glass cLeanIng the burn pot anD coMbuStIon chaMber 1. Vacuum the residues in the burn pot 2.
- Page 25 everY 3/4 DaYS - weekLY aSh Drawer Every 3-4 days check the ash drawer and empty it at least one/twice a week. If there is a lower door, open/remove it. Take out the removable ash drawer and empty it in a special container. Vacuum the area underneath the removable ash drawer.
- Page 26 * on applicable models ENGLISH...
-
Page 27: Routine Maintenance Carried Out By Authorised Technicians
routIne MaIntenance carrIeD out bY authorISeD technIcIanS routine maintenance must be performed at least once a year. As the generator uses pellets as solid fuel, it needs an annual routine maintenance interval that needs to be performed by an authorised technician by only using original spare parts. - Page 28 The images are for illustration purposes Fumes motor (disassembly and cleaning and fumes pipe), new silicone in required points Inspection of gaskets, ash drawer and burn pot door (replace them and apply silicone where required) Combustion chamber (total cleaning of the entire chamber) and ignition plug pipe cleaning Tank (complete emptying and cleaning) Room air fan disassembly and removal of dust and any pellet debris Air intake pipe inspection and any flow sensor cleaning...
- Page 29 The images are for illustration purposes Fumes motor (disassembly and cleaning and fumes pipe), new silicone in required points Inspection of gaskets, ash drawer and burn pot door (replace them and apply silicone where required) Combustion chamber (total cleaning of the entire chamber) and ignition plug pipe cleaning Tank (complete emptying and cleaning) Room air fan disassembly and removal of dust and any pellet debris Air intake pipe inspection and any flow sensor cleaning...
-
Page 30: Displays
Displays Display Reason solution Stove off staRt The start-up phase is in progress pellet feeDing The feeding of the pellet during the ignition phase is in progress ignition The ignition phase is in progress BuRning The start-up phase is in progress opeRant The normal work phase is in progress MoDulation... -
Page 31: Alarms
alaRMs explanation solution Display On: indicates the presence of an alarm Off: indicates the absence of alarms Flashing: indicates the deactivation of the depression sensor. Indicates the presence of an alarm. The alarm can be reset by pressing key 1 for 3 seconds only if the fumes motor has stopped and if 15 minutes have passed from displaying the same alarm. -
Page 32: Guarantee Terms
Extraflame S.p.A. cannot be held liable for injury or damage which may - either directly or indirectly - be caused to persons, animals and property ensuing from failure to observe all the instructions provided in the relevant instruction manual and the warnings regarding installation, use and maintenance of the product, that can also be downloaded on the website. - Page 33 AddITIONAL wARNINGs Š Only use the fuel recommended by the manufacturer. The product must not be used as an incinerator. Š Do not use the product as a ladder or supporting structure. Š Do not place laundry on the product to dry it. Any clothes-horse or similar objects must be kept at due distance from the product. Danger of fire or damage to the coating.
- Page 34 ENGLISH...
- Page 35 ENGLISH...
- Page 36 Extraflame S.p.A. Via Dell’Artigianato, 12 36030 - MONTECCHIO PRECALCINO (VI) - ITALY +39.0445.865911 - +39.0445.865912 - info@extraflame.it - www.lanordica-extraflame.com MADE ITALY design & production TO FIND THE SERVICE CENTRE NEAREST TO YOU CONTACT YOUR DEALER OR CONSULT THE SITE WWW.LANORDICA-EXTRAFLAME.COM...
