pellet stoves UseR MANUAl
UK
ANGELA - ANGELA PLUS
MADE
IN
ITALY
design & production
004276797 - Rev.003

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ANGELA PLUS and is the answer not in the manual?

Questions and answers

Related Manuals for Extraflame ANGELA PLUS

Summary of Contents for Extraflame ANGELA PLUS

  • Page 1 UseR MANUAl ANGELA - ANGELA PLUS MADE ITALY design & production 004276797 - Rev.003...
  • Page 2 ENGLISH...

  • Page 3: Table Of Contents

    ............................................8 FumEs EXHaust sYstEm ........................................8 DEtaILS of aNGELa ....................................9 DEtaILS of aNGELa pLuS ................................10 DuctING SpEcIfIcatIoNS of aNGELa pLuS ..........................11 usE oF supplEmEntarY tHErmostat to control ducting motor ......................11 rEarming ..............................................11 FusE ................................................11 pELLEtS aND LoaDING ..................................12 pELLEt HoppEr - prESSurISED cLoSurE.

  • Page 4: English

    We thank you for having chosen our company; our product is a great heating solution developed from the most advanced technology with top quality machining and modern design, aimed at making you enjoy the fantastic sensation that the heat of a flame gives, in complete safety. Warnings This instructions manual is an integral part of the product: make sure that it always accompanies the appliance, even if transferred to another owner or user, or if transferred to another place.

  • Page 5: Routine Maintenance

    DISABLED PERSONS. Š THE HEARTH DOOR MUST ALWAYS BE CLOSED DURING NORMAL FUNCTIONING OF THE PRODUCT. Š WHEN THE APPLIANCE IS FUNCTIONING AND HOT TO THE TOUCH, ESPECIALLY ALL EXTERNAL SURFACES, ATTENTION MUST BE PAID Š CHECK FOR THE PRESENCE OF ANY OBSTRUCTIONS BEFORE SWITCHING THE APPLIANCE ON FOLLOWING A PROLONGED PERIOD OF INACTIVITY.

  • Page 6: Installation

    InstallatIon general The flue gas exhaust and hydraulic connections must be carried out by qualified personnel who must issue installation conformity documentation compliant with national standards. the installer must provide the owner or person acting for him, according to the legislation in force, with the declaration of conformity, supplied with: 1) the use and maintenance manual of the appliance and of the system components (such as for example, the smoke ducts, chimney, etc.);...
  • Page 7 In the presence of type B gas appliances with intermittent operation not intended for heating, they must have their own aeration and/or ventilation opening. The air inlets must meet the following requirements: Š they must be protected with grids, metal mesh, etc., but without reducing the net useful section; Š...

  • Page 8: Hermetic Installation

    Hermetic installation Angela - Angela Plus is a completely sealed product with respect to the installation environment, which makes it ideal for passive houses, as it does not take air from inside the homes. combustion air To respect the air-tight seal of the stove, the combustion air connection pipe must be directly connected to the outside using specific sealed fittings and pipes.

  • Page 9: Details Of Angela

    DEtAIls oF AnGElA Room air outlet Radio/emergency board On/Off fuse Access to combustion chamber Rear fumes exhaust and ash drawer 230V power supply Upper fumes exhaust Serial input Rearming Supplementary Pellet hopper pressurised closure Combustion air inlet thermostat input ENGLISH...

  • Page 10: Details Of Angela Plus

    DEtAIls oF AnGElA plus Serial input Room air outlet Radio/emergency board Supplementary thermostat input Rearming Ducting thermostat input Access to combustion chamber and ash drawer On/Off Rear fumes exhaust Upper fumes exhaust Ducting fuse Pellet hopper pressurised closure Combustion air inlet...

  • Page 11: Ducting Specifications Of Angela Plus

    DuCtInG spECIFICAtIons oF AnGElA plus The Angela Plus model is fitted with 1 ducting outlet. features: Š diameter of ducting outlet: 80 mm Š maximum recommended ducting length 8m Š temperature controlled ducting Š regulation of air flow speed as a percentage Š...

  • Page 12: Pellets And Loading

    Pellets and loading Pellets are made by subjecting wood shavings i.e. the rejects of pure unpainted wood from sawmills, carpentry products and products from other activities connected to wood working and transformation, to very high pressures. This type of fuel is fully ecological as no glues are used for its compaction. In fact, pellet compactness is guaranteed over time by a natural substance found in wood: lignite.

  • Page 13: Radio/Emergency Card

    Radio/emeRgency caRd The stove is fitted with an emergency radio card located at the side, allowing the basic operation of the stove in the event the LCD handheld remote is damaged or malfunctions. The functions that can be managed from the emergency card are: On/off stove.

  • Page 14: Handheld

    handheld cOnFIGUratIOn hAndheld codIng procedure: 1. disconnect the power supply to the stove. at the same time until the UNIT selection screen appears. 2. press keys 3. using keys select the new UNIT. 4. power the stove. confirm the selected unit within 10 seconds (all leds flash on the radio/emergency card) by pressing the oK key on the handheld.

  • Page 15: Handheld Features

    handheld FeatUres Š The handheld device is fitted with an lcd backlit display. The display remains lit for 5 seconds. After a certain period of time, in order to minimise battery consumption, the display turns off (sleep mode). Š It turns on again after pressing the on/oFF key (6). Š...

  • Page 16: Display

    dIsplay SCREEN IN OPERATION STAND-BY active chrono active Battery low power 1-5 Time Temperature detected in room Set room temperature display text SCREEN WITH EXTERNAL THERMOSTAT CONNECTED TO THE TERMINAL “TA” Time Indicates external supplementary thermostat contact display text ENGLISH...

  • Page 17: General Menu

    General menU fUNCTION fUNCTION Scroll parameters Back - exit key Modify settings on / off key Access menu key fRONT AIR SPEED *DUCTINg ENABLINg SPEED EASY SETUP CHRONO ENABLINg PRg1 PRg2 SETTINgS DATE-TIME PRg3 LANgUAgE PRg4 DISPLAY STAND-BY DELTA T DEgREES **STOVE STATUS RESET...

  • Page 18: First Start-Up Settings

    FIrst start-Up settInGs once the power cord at the back of the generator has been connected, move the switch, also located at the back, to (I). The switch at the back of the generator powers the generator board. The generator remains off and a first screen appears on the panel reading oFF. lIne FreqUency 50/ 60hz If the generator is installed in a country with a frequency of 60hz, the generator will display “power freqUeNcy error".

  • Page 19: Functioning And Logic

    FUnctIOnInG and lOGIc IGnItIOn once the previously listed points have been checked, press the key for three seconds until the stove lights up. during ignition, the stove will check for a flame for a period of 15 minutes. once the limit temperature has been reached, the stove interrupts the ignition phase and switches to prepArATIon.

  • Page 20: Front Air

    FrOnt aIr From the menu, it is possible to adjust the speed (-2, -1, 0, +1, +2) of the front fan. To adjust the speed : oK > froNT aIr > SpeeD dUctInG From the menu, it is possible to enable/disable and adjust the ducting speed (-2, -1, 0, +1, +2).

  • Page 21: Chrono

    chrOnO This function allows the programming of automatic stove ignition and switch-off. By factory default CHRONO is disabled. The chrono allows the programming of 4 time slots within a day, which can be used every day of the week. For each time slot, it is possible to set ignition and switch-off times, specific days of application, desired temperature and set power. current day and time settings are essential for the correct operation of the chrono.
  • Page 22 CHRONO > ENABLINg enable/disable entire set chrono PRg1 > ENABLE PRg 1 on/off/ comfort enable/disable prg 1 START PRg1 off-00:00-23:50 on time prg1 STOP PRg1 off-00:00-23:50 off time prg1 MONDAY...SUNDAY on/off enable/disable days of prg1 SET PRg1 Low-Ta - 07- 40 °c - hoT Set thermostat prg1 POWER PRg1 Set power prg1...
  • Page 23 EXAMPLE Of CHRONO WITH LINkED TIMES/TIME SLOTS Time slot 02:00 08:00 16:30 23:00 power 02:00 08:00 16:30 23:00 Set temperature 22° 18° 02:00 08:00 16:30 23:00 start 02:00 Time slot 1 power 3 - set temp 22°c stop 23:00 start 08:00 Time slot 2 power 1 - set temp 18°c stop 16:30...

  • Page 24: Settings

    settInGs Š DATE-TIME Š LANgUAgE See chApTer: FIrST STArT-up SeTTIngS. Š SET DEgREES dIsplay The "DISPLAY" menu allows: Š Set timer for display backlight switch-off. Š regulation of dISplAy contrast Š Set timer for display switch-off (sleep Š Activation/deactivation of backlight. mode).

  • Page 25: Delta T

    delta t This function allows the hysteresis limit to be set for stove switch-on and switch-off DeLTa T, used as an interval of regulation in the event the room temperature is not managed by an external thermostat. The exact switch-on temperature is SeT ThermoSTaT - DeLTa T. The switch-off temperature is SeT ThermoSTaT + DeLTa-T.

  • Page 26: Delayed Switch-Off

    delayed swItch-OFF The appliance can be programmed for delayed switch-off. For example, if it is 8.00pm and delayed switch-off is set to 1 hour, at 9.00pm the stove will automatically switch off. When keys 6 + 2 are pressed and held, the “delAyed SWITch-oFF” screen opens up (this setting can only be configured when the machine is in preparation or work mode).

  • Page 27: Cleaning And Maintenance

    TO FIND OUT WHERE YOUR NEAREST SERVICE CENTRE IS, CONTACT YOUR DEALER OR GO TO THE WEBSITE: WWW.LANORDICA-EXTRAFLAME.COM Cleaning and maintenanCe always follow the instruCtions with maximum safety! Š Make sure that the power cord is unplugged because the generator may have been programmed to switch on.

  • Page 28: Ash Drawer

    every day burn Pot and Combustion Chamber: Š Extract any residue in the burn pot Š Completely remove the burn pot from the relevant compartment; Š Extract the ash from the burn pot housing, ignition plug holder tube and combustion chamber.

  • Page 29: Routine Maintenance Performed By Qualified Technicians

    BURN POT HOLES TO FIND OUT WHERE YOUR NEAREST SERVICE CENTRE IS, CONTACT YOUR DEALER OR GO TO THE WEBSITE: WWW.LANORDICA-EXTRAFLAME.COM routine maintenanCe Performed by Qualified teChniCians routine maintenance must be performed at least once a year. Given the generator uses pellets as solid fuel, it requires annual routine maintenance, which must be performed by a Qualified technician, using only original spare parts.
  • Page 30 TO FIND OUT WHERE YOUR NEAREST SERVICE CENTRE IS, CONTACT YOUR DEALER OR GO TO THE WEBSITE: WWW.LANORDICA-EXTRAFLAME.COM THE IMAGES ARE FOR ILLUSTRATIVE PURPOSES. Fumes motor (disassembly and cleaning and fumes and "T" pipes), new silicone in the specified points...
  • Page 31 TO FIND OUT WHERE YOUR NEAREST SERVICE CENTRE IS, CONTACT YOUR DEALER OR GO TO THE WEBSITE: WWW.LANORDICA-EXTRAFLAME.COM THE IMAGES ARE FOR ILLUSTRATIVE PURPOSES. Fumes motor (disassembly and cleaning and fumes and "T" pipes), new silicone in the specified points...

  • Page 32: Readings

    Readings display Reason Generator off sTaRT The start-up phase is in progress pelleT loading Continuous pellet loading is in progress during the ignition phase igniTion The ignition phase is in progress pRepaRaTion The preparation phase is in progress WoRk The normal work phase is in progress ModulaTion The generator is working at minimum level final cleaning...

  • Page 33: Guarantee Terms

    Extraflame S.p.A. cannot be held liable for injury or damage which may - either directly or indirectly - be caused to persons, animals and property ensuing from failure to observe all the instructions provided in the relevant instruction manual and the warnings regarding installation, use and maintenance of the product, that can also be downloaded on the website.
  • Page 34 AddITIONAL wARNINGs Š Only use the fuel recommended by the manufacturer. The product must not be used as an incinerator. Š Do not use the product as a ladder or supporting structure. Š Do not place laundry on the product to dry it. Any clothes-horse or similar objects must be kept at due distance from the product. Danger of fire or damage to the coating.
  • Page 35 ENGLISH...
  • Page 36 Extraflame S.p.A. Via Dell’Artigianato, 12 36030 - MONTECCHIO PRECALCINO (VI) - ITALY   +39.0445.865911 -  +39.0445.865912 -  info@extraflame.it - www.lanordica-extraflame.com MADE ITALY design & production TO FIND THE SERVICE CENTRE NEAREST TO YOU CONTACT YOUR DEALER OR CONSULT THE SITE WWW.LANORDICA-EXTRAFLAME.COM...
