Running the Demo

1. Power on the ATSAMB11 by connecting the USB cable.
2. Open a console window using TeraTerm or any equivalent serial port monitor application and
connect to the corresponding COM port enumerated on the PC. Configure the COM Port with the
following settings: Baudrate 115200, Parity None, one Stop bit, one Start bit, no Hardware
Handshake.
3. Press the Reset button on the ATSAMB11 board.
4. The device is now in advertising mode.
Figure 7-1.
Initializing Find Me Application
Initializing SAMB11
BD Address:0xF8F005F23FFF, Address Type:0
The Supported Services in Find Me Profile are:
-> Immediate Alert Service
Bluetooth device is in Advertising Mode
5. On the iPhone
scan for devices. ATMEL-FMP will be appear amongst the devices scanned. Click on ATMEL-FMP
to connect to the ATSAMB11 device.
Figure 7-2.
6. Once connected, the client side will request for the pairing procedure with the iPhone. The console
log provides a guidance for the user to enter the pass-key on iPhone.
ATSAMB11 BluSDK SMART – Find Me Profile – Getting Started Guide [USER GUIDE
8
8
Atmel-42612A-ATSAMB11-BluSDK-SMART-Find-Me-Profile-Getting-Started-Guide_UserGuide_112015
Console Display for Device in Advertising Mode
®
, enable Bluetooth in the Settings page. Start the Atmel SmartConnect App and
ATMEL-FMP in Device Discovery Atmel SMART App
]
