SOUTHERN ENTERPRISES INC.
RELAX...If you can follow a few easy, step-by-step directions
in order .YOU CAN ASSEMBLE THIS ITEM.
PLEASE FIND HARDWARE IN RED POLYBAG BEFORE DISCARDING PACKING MATERIAL.
NOTE: PLEASE DO NOT OVERTIGHTEN CAM LOCKS!
(1) MEDIUM MACHINE SCREWS
(Ø1/4"X1")
(2) LARGE MACHINE SCREWS
(Ø1/4"X1-1/2")
(3) X-LARGE MACHINE SCREWS
(Ø1/4"X2-1/4")
(4) T-BOLTS
(5) PLASTIC PLUGS
(6) LARGE WOOD DOWELS
(7) SMALL WOOD DOWELS
HARDWARE LIST
4PCS
8PCS
4PCS
12PCS
12PCS
8PCS
Ø8x30mm
12PCS
Ø6x20mm
STYLE NO:
WHITE ARCH-TOP
(11) METAL HINGES
(12) KNOBS
(13) SMALL MACHINE SCREWS
(Ø5/32"X5/8")
(14) SHELF SUPPORTS
(15) PLASTIC ANCHORS
(16) LARGE FLAT HEAD WOOD
SCREWS (Ø4X25mm)
(17) SMALL FLAT HEAD WOOD
SCREWS (Ø3X10mm)
BE6621
SPACESAVER
2PCS
4PCS
4PCS
4PCS
2PCS
4PCS
4PCS
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Southern Enterprises BE6621
Summary of Contents for Southern Enterprises BE6621
- Page 1 BE6621 STYLE NO: WHITE ARCH-TOP SOUTHERN ENTERPRISES INC. SPACESAVER RELAX...If you can follow a few easy, step-by-step directions in order .YOU CAN ASSEMBLE THIS ITEM. PLEASE FIND HARDWARE IN RED POLYBAG BEFORE DISCARDING PACKING MATERIAL. NOTE: PLEASE DO NOT OVERTIGHTEN CAM LOCKS!
-
Page 2: Parts List
(8) MEDIUM FLAT HEAD WOOD 16PCS (18) RIGHT METAL HINGES SCREWS (Ø3X15mm) (9) X-LARGE FLAT HEAD WOOD 2PCS (19) LEFT METAL HINGES SCREWS (Ø4X38mm) (10) PAN HEAD WOOD SCREWS 26PCS (20) METAL STOPPER 2PCS (Ø2.6X10mm) PARTS LIST (A) TOP PANEL (L) DIVIDER (B) UPPER LEFT SIDE PANEL (M) LOWER RIGHT SIDE FRAME... -
Page 3: Assembly Instruction
(F) DRAWER FRONT 2PCS (Q) MIDDLE BACK PANEL (G) DRAWER LEFT SIDE 2PCS (R) LOWER BACK PANEL (H) DRAWER BACK 2PCS (S) RIGHT DOOR (I) DRAWER BOTTOM 2PCS (T) LEFT DOOR (J) DRAWER RIGHT SIDE 2PCS (U) ADJUSTABLE SHELF (K) BOTTOM PANEL ASSEMBLY INSTRUCTION SELECT A SMOOTH, SOFT SURFACE TO PREVENT SCRATCHING FINISH. - Page 4 INSERT MEDIUM FLAT HEAD WOOD SCREWS (Ø3X15mm) (8) THROUGH PREDRILLED HOLES ON OUTSIDE OF DRAWER RIGHT PANEL (J) AND TIGHTEN INTO PREDRILLED HOLES ON ENDS OF DRAWER FRONT PANEL (F) AND DRAWER BACK PANEL (H). SLIDE DRAWER BOTTOM PANEL (I) INTO GROOVES ON DRAWER FRONT PANEL (F) AND DRAWER BACK PANEL (H) AND ALIGN WITH GROOVE ON DRAWER RIGHT PANEL (J).
- Page 5 FIGURE 3 FIGURE 4 ( 1 0 ) ( P ) ( Q ) ( R ) FIGURE 5...
- Page 6 INSERT METAL HINGES (11) INTO PREDRILLED HOLES ON TOP EDGES OF LEFT AND RIGHT DOORS (S, T) AND FIT INTO CORRESPONDING HOLES ON UNDERSIDE OF TOP PANEL (A). INSERT LEFT AND RIGHT METAL HINGES (18, 19) INTO PREDRILLED HOLES ON UPSIDE OF UPPER FIXED SHELF (D).
-
Page 7: Parts Replacement Form
Parts will not be available for items arriving fully assembled. NOTE: PLEASE DO NOT OVERTIGHTEN CAM LOCKS! "We will ship parts if available" "This is not a warranty" PARTS REPLACEMENT FORM STYLE NO : BE6621 Customer Name PARTS PART QUANTITY...
