Summary of Contents for Southern Enterprises Wyndmere BC401900TX
- Page 1 BC401900TX Wyndmere Shoe Bench For assistance with assembly, contact: Southern Enterprises Inc. Assembly Instruction Customer Service 1-800-633-5096 service@seidal.com www.seidal.com Page 1...
-
Page 2: Parts List
Wyndmere Shoe Bench Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures. - Page 3 Quantity of 1 Lower Back Panel Quantity Quantity Quantity of 20 of 20 of 20 Cam-Bolt Cam-Lock PVC Cover Quantity Quantity Quantity of 28 of 18 of 8 Wood Dowel Round Head Screw Bolt Dia 8 x 30mm Dia 1/8” x 1/2” Dia 3/16”...
- Page 4 Wyndmere Shoe Bench Assembly Instructions Slide Upper Fixed Shelf Panel (F) into Middle Vertical Panel (B) as shown. Figure 1 Insert Wood Dowels (4) into corresponding holes in Upper Fixed Shelf Panel (F) to connect Vertical Panels (C). Figure 2 Page 4...
- Page 5 Slide Lower Fixed Shelf Panel (D) into Vertical Panels (C) as shown. Figure 3 Screw with finger to help align cam bolts before using screwdriver. Insert Cam Locks (2) into predrilled holes on top and bottom of Middle Vertical Panel (B). Insert Wood Dowels (4) into corresponding holes on Vertical Panels (C) and Middle Vertical...
- Page 6 Insert Cam Locks (2) into corresponding holes on assembled unit from Figure 4. Screw Cam Bolts (1) and insert Wood Dowels (4) into corresponding holes on Left Frame (G) and Right Frame (H). Attach Left Frame (G) and Right Frame (H) to assembled unit from Figure 4 by inserting Cam Bolts (1) and Wood Dowels (4) into corresponding holes until...
- Page 7 Attach Back Panels (O & P) to assembled unit with Round Head Screws (5). Tighten Round Head Screws (5) with Phillips screwdriver. Figure 7 Attach Right Drawer Side (L) and Left Drawer Side (K) to Drawer Back (M) with Bolts (6). Tighten Bolts (6) with Philips screwdriver.
- Page 8 Insert drawers into assembled unit. Please make sure drawers glide smoothly with slides attached to unit. Figure 9 Your Wyndmere Shoe Bench is ready for use. Figure 10 Page 8...
-
Page 9: Parts Replacement Form
90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. For product issues, please contact Southern Enterprises at 800-633-5096 (toll-free) / 972-869-0111 (Dallas) Mon-Fri 9am – 4pm CST, or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
