- Page 1 BC946200TX Large Artisan Storage Bench For assistance with assembly, contact: Southern Enterprises Inc. customer service 1-800-633-5096 service@seidal.com Assembly Instructions www.seidal.com PO#: Page1...
- Page 2 Large Artisan Storage Bench Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures.
- Page 3 Quantity Quantity Quantity of 1 of 1 of 1 middle leg back rail back panel Quantity Quantity Quantity of 1 of 1 of 1 drawer front panel drawer left side panel drawer right side panel Quantity Quantity Quantity of 1 of 1 of 1 drawer back panel...
- Page 4 Quantity Quantity Quantity of 2 of 5 of 5 short bolt long bolt ø1/4” x 7/8”L flat head screw ø1/4” x 1-1/2”L ø1/8”x1”l Quantity Quantity Quantity of 1 of 2 of 10 sticker cover handle handle bolt ø5/32” x 1/2”L Care and Cleaning Instructions: For replacement parts or questions, please Before using, wipe with a clean, dry cloth.
- Page 5 Page 4 Large Artisan Storage Bench Assembly Instructions Connect Apron back panel (B) to apron side panels (C) with bolts (7) and wood dowels (1). Tighten bolt (7) with phillips screwdriver as shown. Figure 1 Connect assembled to top panel (A) with bolts (8) and wood dowels (1).
- Page 6 Insert cam locks (4) into holes on drawer back panel (S). Screw cam bolts (3) into drilled holes on drawer left side panel (Q) and drawer right side panel (R). Attach drawer left side panel (Q) and drawer right side panel (R) to drawer back panel (S) by inserting cam bolts (3) into corresponding holes until they meet.
- Page 7 Insert cam locks (4) into holes on assembled unit. Screw cam bolts (3) into holes on drawer front panel (P). Attach assembled unit to drawer front panel (P) by inserting cam bolts (3) into corresponding holes until they meet. Tighten by rotating cam locks (4) clockwise with phillips screwdriver.
- Page 8 Insert cam locks (4) into holes on left vertical panel (F) and right vertical panel (G). Screw cam bolts (3) into holes on bottom panel (O). Attach left vertical panel (F) and right vertical panel (G) to bottom panel (O) by inserting wood dowels (1) and cam bolts (3) into corresponding holes until they meet.
- Page 9 Attach small upper vertical panels (J) to assembled unit by inserting wood dowels (2) into corresponding holes until small upper vertical panels (J) and assembled unit meet. Figure 9 Insert cam locks (4) into holes on assembled unit and back rail (M). Screw cam bolts (3) into holes of left side frame (D) and right side frame (E).
- Page 10 Attach middle leg (O) to bottom panel as shown, tighten by hand. Figure 11 Insert cam locks (4) into holes on assembled unit. Screw cam bolts (3) into holes on underside of top panel (A). Attach top panel to assembled unit by inserting wood dowels (1) and cam bolts (3) into corresponding holes until top panel and assembled unit meet.
- Page 11 Use screws (9) to connect back rail to top panel as shown. Tighten screws (9) with phillips screwdriver. Figure 13 Connect back panel (N) to assembled unit with screws (6). Tighten screws (6) with phillips screwdriver. Figure 14 Page11...
- Page 12 Screw bolts (5) into holes on vertical panel as shown. Attach assembled drawer box into assembled unit as shown. Make sure the bolt (5) holds the drawer box stably. Figure 15 Place seat cushion (L) on top panel as shown. Figure 16 Page12...
- Page 13 Now your new large Artisan storage bench is ready to use. Figure 17 Page13...
-
Page 14: Parts Replacement Form
90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
