- Page 1 BC403400TX Dynasty Storage Bench For assistance with assembly contact: Southern Enterprises, Inc. Customer Service 1-800-633-5096 Assembly Instructions service@seidal.com www.seidal.com PO#:13396 Page 1...
- Page 2 Dynasty Storage Bench Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures.
- Page 3 Quantity Quantity Quantity of 2 of 2 of 2 Drawer Right Side Panel Drawer Back Panel Drawer Bottom Panel Quantity Quantity Quantity of 1 of 1 of 1 Middle Leg Left Side Door Right Side Door Quantity of 1 Seat Cushion Quantity Quantity Quantity...
- Page 4 Quantity Quantity Quantity of 4 of 26 of 8 Drawer Stopper: Sticker Cover Screw: Dia1/8”x1/2”L Dia 1/4”x23mm Quantity Quantity of 2 of 2 Drawer Handle Magnet Care and Cleaning Instructions: Before using, wipe with a clean, dry cloth. For replacement parts or questions, please Periodically apply furniture wax to renew call Customer Service at 1-800-633-5096.
- Page 5 Dynasty Storage Bench Page 4 Assembly Instructions Start by hand to help align bolts. Use Wood Dowels (1) and Bolts (2) to connect Apron Back Panel (B) to Apron Side Panels (C). Tighten Bolts (2) with Phillips screwdriver as shown. Figure 1 Start by hand to help align bolts.
- Page 6 Start by hand to help align Cam Bolts. Insert Cam Locks (3) into corresponding holes on Drawer Back Panel (N). Screw Cam Bolts (4) into holes on Drawer Left Side Panel (L) and Drawer Right Side Panel (M). Attach Drawer Left Side Panel (L) and Drawer Right Side Panel (M) to Drawer Back Panel (N) by inserting Cam Bolts (4) into corresponding holes until all...
- Page 7 Start by hand to help align Cam Bolts. Insert Cam Locks (3) into corresponding holes on assembled unit from Figure 4. Screw Cam Bolts (4) into holes on Drawer Front Panel (K). Attach assembled unit from Figure 4 to Drawer Front Panel (K) by inserting Cam Bolts (4) into corresponding holes until all panels meet.
- Page 8 Start by hand to help align Cam Bolts. Insert Cam Locks (3) into corresponding holes on Middle Panel (F) and (G). Screw Cam Bolts (4) into holes on Bottom Panel (H). Attach Middle Panel (F) and (G) to Bottom Panel (H) by inserting Cam Bolts (4) into corresponding holes until all panels meet.
- Page 9 Start by hand to help align Cam Bolts. Insert Cam Locks (3) into corresponding holes on assembled unit from Figure 8. Screw Cam Bolts (4) into holes on the underside of the Top Panel. Attach the Top Panel to assembled unit from Figure 8 by inserting Cam Bolts (4) into corresponding holes until all panels meet.
- Page 10 Start by hand to help align screws. Use Screws (8) to connect Back Panel (J) to assembled unit from Figure 10 as shown. Tighten Screws (8) with Philips screwdriver. Figure 11 Screw Drawer Stoppers (7) into corresponding holes on assembled unit. Attach Drawers into assembled unit as shown.
- Page 11 Start by hand to help align screws. Use Screws (11) to connect Magnetic (11) into the pre-drilled holes on the underside of Top Panel (A). Figure 13 Insert Shelf Brackets (6) into corresponding holes. Insert Adjustable Shelf (I) in the arrows direction.
- Page 12 Use Bolt (5) to attach Door Handle (5) to Left Side Door (Q). Tighten Bolt (5) with Phillips screwdriver. Repeat step for Right Side Door (R). Figure 15 Start with finger to help align screws. Use Screws (8) to connect Left Side Door (Q) into holes of Left Middle Panel (F) on assembled unit.
- Page 13 Place Seat Cushion (S) on Top Panel as shown. Figure 17 Now your new Dynasty Storage Bench is ready for use. Figure 18 Page 13...
-
Page 14: Parts Replacement Form
90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
