Summary of Contents for Southern Enterprises BE908100TX
- Page 1 BE907100TX- ESPRESSO BT908100TX- WHITE RESERVE DELUXE SPACESAVER For assistance with assembly contact: Assembly Instructions Southern Enterprises, Inc. Customer Service 1-800-633-5096 service@seidal.com wwww.seidal.com...
- Page 2 RESERVE DELUXE SPACESAVER Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw.
- Page 3 RESERVE DELUXE SPACESAVER Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw.
- Page 4 RESERVE DELUXE SPACESAVER Assembly Instructions Assembly Instructions: Wood may scratch easily, Be careful when assembling. Do not scratch. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated on the front page. Attach 1pc Magnet (6) to the Top Panel (E) and 2pcs Plastic Drawer Stoppers (5) to the Bottom Frame...
- Page 5 RESERVE DELUXE SPACESAVER Assembly Instructions Secure the Top Right Side Frame (B) to the unit assembled on step3 with 6pcs Big Bolts (1), tighten by screw driver (not included in hardware list) as figure show. Figure 4 Attach 2pcs Magnet Pins (10) to the Left and Right Doors (H/I) with 2pcs Wood Screws (11) as figure shown.
- Page 6 RESERVE DELUXE SPACESAVER Assembly Instructions Connect the Drawer Sides (L) ,Drawer backs (M), Drawer bottoms (P) and the Left and Right Front Drawer Panel(O,N) with 16pcs Long Wood Screws (3) as figure shown, then fix the 2pcs Knobs (7) to the Left and Right Front Drawer Panel (O,N) with 2 pcs Short Bolt (8) as figure shown.
- Page 7 RESERVE DELUXE SPACESAVER Assembly Instructions Fix the 2pcs Wall Anchors (15) into the wall. Then attach 4 pcs Metal Pins(12) to back of space saver and wall by using 2 pcs Wood Screw (13) and 2 pcs Wood Screw (14) ,tie the Metal Pins with the 2pcs Plastic Chains (16) as figure shown.
- Page 8 Parts will not be available for items arriving fully assembled. Parts will be sent if available from SEI Please contact Southern Enterprises at 800-633-5096 or in Dallas (972) 869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues with your purchase. Please ask for a customer service representative for issues involving damages or replacement parts.
