- Page 1 BC962800TX Boise Two-Drawer Storage Bench For assistance with assembly, contact: Southern Enterprises Inc. Assembly Instructions Customer Service: 1-800-633-5096 service@seidal.com www.seidal.com PO#: Page | 1...
- Page 2 Boise Two-Drawer Storage Bench Parts List Please review all parts and hardware before disposing of any packaging. Before beginning assembly, separate each type of hardware. Carefully study the diagrams below and check that you have all parts indicated. Call Customer Service if missing hardware. Using the incorrect hardware will cause damage.
- Page 3 Quantity Quantity Quantity of 6 of 12 of 3 Bolts Wood Dowels Screws Dia. 1/4"x1-1/2” L Dia. 8mm x 30mm Dia. 5/32” x 1-1/4"L Quantity Quantity Quantity of 10 of 20 of 1 Wood Plugs Screws Allen Wrench Dia. 5/32” x 1"L 1/4”...
- Page 4 Boise Two-Drawer Storage Bench Assembly Instructions Screw with fingers to help align before using a screwdriver. Connect Bottom Panel (3) and Divider (6) with 2pcs Wood Dowels (B) and 1pc Wood Screw (C). Tighten screw with screwdriver. Figure 1 Insert Back Panel (8) into the grooves in the bottom Seat Back (5) and the rear of Bottom Panel (3).
- Page 5 Attach Left Side Frame (1), Right Side Frame (2), and Front Brace (4) to the assembled unit from Figure 2 and with Wood Dowels (B), Bolts (A/I) and T-nuts (J). Note: T-nuts are inserted into their respective holes in the rear of Seat Back (5).
- Page 6 Attach Drawer Side Panels (10/11) to Drawer Back Panels (12) using Wood Screws (E). Tighten screws with Phillips screwdriver. Insert Drawer Bottom Panels (13) into grooves of Panels (10/11/12). Attach Drawer Front Panels (9) to assembled unit using Wood Screws (E).
- Page 7 For product issues, please contact Southern Enterprises at 800-633-5096 (toll-free) / 972-869-0111 (Dallas), Mon-Fri 9am – 4pm CST, or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
