Southern Enterprises BC947200TX Assembly Instructions Manual

Large apothecary storage bench
Hide thumbs

Advertisement

Quick Links

Download this manual
BC947200TX
Large Apothecary Storage Bench
For assistance with assembly, contact:
Southern Enterprises Inc.
Customer Service 1-800-633-5096
service@seidal.com
Assembly Instructions
www.seidal.com
PO#:
Page1

Advertisement

loading
Need help?

Need help?

Do you have a question about the BC947200TX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Southern Enterprises BC947200TX

Summary of Contents for Southern Enterprises BC947200TX

  • Page 1 BC947200TX Large Apothecary Storage Bench For assistance with assembly, contact: Southern Enterprises Inc. Customer Service 1-800-633-5096 service@seidal.com Assembly Instructions www.seidal.com PO#: Page1...
  • Page 2 Large Apothecary Storage Bench Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures.
  • Page 3 Quantity Quantity Quantity of 1 of 1 of 2 drawer front panel back panel middle leg Quantity Quantity Quantity of 2 of 2 of 2 drawer left side panel drawer right side panel drawer back panel Quantity Quantity of 2 of 1 drawer bottom panel seat cushion...
  • Page 4 Quantity Quantity Quantity of 5 of 2 of 5 screw ø1/8”x1”l bolt ø1/4”*1-1/2”l bolt ø1/4”*7/8”l Quantity Quantity Quantity of 8 of 16 of 8 sticker cover handle screw ø1/8”x1/2”l Care and Cleaning Instructions: For replacement parts or questions, please Before using, wipe with a clean, dry cloth. call customer service at 1-800-633-5096.
  • Page 5 Large Apothecary Storage Bench Assembly Instructions Connect Apron back panel (B) to apron side panels (C) with bolts (7) and wood dowels (1). Tighten bolt (7) with phillips screwdriver as shown. Figure 1 Connect assembled to top panel (A) with bolts (7) and wood dowels (1).
  • Page 6 Insert cam locks (3) into holes on drawer back panel (R). Screw cam bolts (2) into holes on drawer left side panel (Q) and drawer right side panel (P). Attach drawer left side panel (Q) and drawer right side panel (P) to drawer back panel (R) by inserting cam bolts (2) into corresponding holes until they meet.
  • Page 7 Insert cam locks (3) into holes on assembled unit. Screw cam bolts (2) into holes on drawer front panel (O). Attach assembled unit to drawer front panel (O) by inserting cam bolts (2) into corresponding holes until they meet. Tighten by rotating cam locks (3) clockwise with phillips screwdriver.
  • Page 8 Insert cam locks (3) into holes on bottom panel (H). Screw cam bolts (2) into holes on lower back rail (K) and front rail (L). Attach lower back rail (K) and front rail (L) to bottom panel (H) by inserting wood dowels (1) and cam bolts (2) into corresponding holes until lower back rail (K),front rail (L), and bottom panel (H)
  • Page 9 Insert cam locks (3) into holes on assembled unit. Screw cam bolts (2) into holes on left frame (D) and right frame (E). Attach left frame (D) and right frame (E) to assembled unit by inserting cam bolts (2) into corresponding holes until they meet.
  • Page 10 Connect upper back rail (J) to top panel with screws (9). Tighten screws (9) with philips screwdriver. Attach middle leg (N) to bottom panel as shown, tighten by hand. Figure 11 Connect back panel (O) to assembled unit with screws (5). Tighten screws (5) with philips screwdriver.
  • Page 11 Install shelf pins (4) to assembled unit. Install two adjustable shelves (I) in the arrows direction. Make sure the shelf pins (4) hold the adjustable shelves (I) stably. Figure 13 Screw bolts (6) into holes on side legs as shown. Attach assembled drawer box into assembled unit.
  • Page 12 Place seat cushion (T) on top panel as shown in figure 15. Figure 15 Now your new large Apothecary storage bench is ready to use. Figure 16 Page12...

  • Page 13: Parts Replacement Form

    90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
