PARTS LIST

NO.
Description
1 Main Frame
2 Upright Support
3 Front Stabilizer Weld
4 Seat Weld
5 Handlebar Weld
6 Adjustable Tube
9 Rear Stabilizer
12 Crossed Pan Bolt M5*10
13 Display
14 Crossed Pan Bolt M5*45
15 Flat Washer D5
16 Resistance Controller
17 Inner Hexagon Pan Bolt M8*15
18 Flat Washer φ16*φ8.5*1.5
19 Arced Washer φ16*φ8.5*1.5
20 Mid Wire 1 wire length 600mm
21 Mid wire of Pulse 1 wire length 600mm
22L/R Pedal(L&R)
24 Crank
26 Square Bolt M8*42
27 Mid wire of Pulse wire length 800mm
33 Needle Type Sensor Wire length 500mm，with support
34 Mid Wire of Pulse 2 wire length 1600mm
35 Resistance Controller Down Wire
52 Domed Nut M8
69 Seat Cushion
70 Inner Hexagon Pan Bolt M8*16
71 Inner Hexagon Pan Bolt M8*45
72 Spring Washer Ring D8
76 Square Bolt M8*62
78 Brake Handlebar
79 Inner Hexagon Cylinder Screw M6*15
80 Axle
88 Back Cushion
90 Inner Hexagon Bolt M8*50
A Crossed Multifunctional Wrench S13-14-15
B Inner Hexagon Wrench S5*30*80
-6-
Qté
1
1
1
1
1
1
1
2
1
1
1
1
4
14+2
6
1
2
1
1
2
2
1
2
1
6
1
4
4
4
4
1
2
1
1
2
1
1
