DT 2-wire System
Quik Start Guide
ATTENTION:
This is an abbreviated Installation Manual, addressing
Wiring and Programming of the DT System only. For all
the detail information of DT 2-wire system, please refer
to the DT Technical Manual.
DT-ENG-QSG-V1 20091221
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DMR11-D8 and is the answer not in the manual?

Questions and answers

Related Manuals for 2easy DMR11-D8

Summary of Contents for 2easy DMR11-D8

  • Page 1 DT 2-wire System Quik Start Guide ATTENTION: This is an abbreviated Installation Manual, addressing Wiring and Programming of the DT System only. For all the detail information of DT 2-wire system, please refer to the DT Technical Manual. DT-ENG-QSG-V1 20091221 - 1 -...

  • Page 2: System Wirings And Connections

    1. System Wirings and Connections 1.1. IN-OUT wiring without any distributor [1]: Door Station, when there is only one Door Station, CALL UNLOCK TALK/MON 3 4 5 6 the DIP bit-1 and bit-2 should be set to 00. IN-USE Code=32, DIP-6=on [2]: Power Supply(PS5), MUST be installed side by side with the DPS unit.
  • Page 3 1.2. IN-OUT wiring with DBC One-user distributor CALL UNLOCK TALK/MON IN-USE [1]: Door Station, when there is only one Door Station, 3 4 5 6 Code=32, DIP-6=on the DIP bit-1 and bit-2 should be set to 00. [2]: Power Supply(PS5), MUST be installed side by side with the DPS unit.
  • Page 4 1.3. Star wiring with 4 output distributor DBC-4 CALL CALL UNLOCK UNLOCK TALK/MON TALK/MON 3 4 5 6 3 4 5 6 IN-USE IN-USE Code=32, DIP-6=on Code=31, DIP-6=on CALL CALL UNLOCK UNLOCK TALK/MON TALK/MON 3 4 5 6 3 4 5 6 IN-USE IN-USE Code=29, DIP-6=on...
  • Page 5 1.4. Multi Door Station wiring CALL CALL UNLOCK UNLOCK TALK/MON TALK/MON IN-USE IN-USE 3 4 5 6 3 4 5 6 Code=4, DIP-6=on Code=3, DIP-6=on CALL CALL UNLOCK UNLOCK TALK/MON TALK/MON IN-USE IN-USE 3 4 5 6 3 4 5 6 Code=2, DIP-6=on Code=1, DIP-6=on DPS-4...
  • Page 6 1.5. CCTV wiring with DCU CALL CALL UNLOCK UNLOCK TALK/MON TALK/MON IN-USE IN-USE 3 4 5 6 3 4 5 6 Code=4, DIP-6=on Code=3, DIP-6=on CALL CALL UNLOCK UNLOCK TALK/MON TALK/MON IN-USE IN-USE 3 4 5 6 3 4 5 6 Code=2, DIP-6=on Code=1, DIP-6=on 1 2 3 4 5 6...

  • Page 7: Din Installation

    2. Parts and Installations 2.1. PS5 - Power Supply The PS5 power supply unit is designed for DT system to supply up to 32 Monitors and total 4 Door Stations at the same time. • Universal AC input/full range. • Multi protection: short sircuit, overload, over voltage •...
  • Page 8 2.2. DPS - DT Power Separator DPS: This unit is a power supply adaptor for the PS5 or PS4 power supply, it transfers the power from the power supply to the suitable power for the non-polarity bus. Note that the DPS must work together with the PS5 or PS4 power supply. Technical Specifications(DPS) Connect to Power Supply(PS5)

  • Page 9: Din Rail Mounting

    2.4. DBC-4 - DT 4 output Branch Controller DBC-4 (4 output Branch Controller)Distributor is a 4 output user distributor for DT system, to approach the star topology connection in the apartment system. See Section 3 Cables and Connection for detail connection information. set to 120 for the last DBC-4 DBC-4 on the building, the others...

  • Page 10: Door Station Mounting

    2.7. Door Station Mounting Camera Angle adjustment Open the mounting box of the panel, use a cross screw to adjust the view angle of the camera before installation. Installation with expanding panel Jointer*2 Stopper T/R - +12V T/R+ LK - (GND) LK+(COM) N.O.

  • Page 11: Function Descriptions

    2.8. Door Station DIP setting Total 6 bits in the DIP switches can be configured. The switches can be modified either before or after installation. ON(1) OFF(0) Bit definition Bit state Function Descriptions Default setting, ID = 0, set to the first Door Station. 3 4 5 6 ID = 1, set to the second Door Station.

  • Page 12: Monitor Mounting

    “03”, system will launch a call to the Monitor which programmed with “03” User Code. The User Code array on panels has been pre-defined as below, that’s the default mapping as follow: DMR11-S4 EP11-S12 EP11-S12 DMR11-D8 EP11-D24 - 12 -...
  • Page 13 3.3. Monitor User Code Setup Bit-6 line terminal setting: Setting Setting state state ON(1) OFF(0) Monitor not Monitor at at the end of the end of 1 2 3 4 5 the line. 1 2 3 4 5 the line. Bit state User Code Bit state...
  • Page 14 4. Proximity ID Card Operation 4.1. Introduction • Up to 1000 user cards can be registered by the Door Station. • Easy management with LED state and Sound hint. • There are two master cards, one card and one MASTER CARD ADD MASTER CARD DELETE card, When adding a new master card, the old one will be replaced automatically.
  • Page 15 4.6. Add user cards by Room: Press a certain button on Show the MASTER the Door Station, then Show the MASTER card CARD ADD show the cards which to CARD ADD card in again to confirm and be assigned to this Room. standby exit.
  • Page 16 5. Quik Debug 5.1. Online search Online search function is designed for the purpose of getting a quick view of the Monitors installing situations, or to check if each of them works or not. It is very useful for installation maintain. When the Online search is acting, the Door Station will search every Monitor with the User Code from 1 to 32.
