SC9-TOCCATA • CompactPCI® Serial CPU Board • 11th Generation Intel® Processors

Standards

Term Document
CompactPCI® CompactPCI® Serial Specification, PICMG® CPCI-S.0
Serial
DisplayPort VESA DisplayPort Standard Version 1.4a,
DisplayPort Alt Mode on USB Type-C
Ethernet IEEE Std 802.3
2.5GBASE-T, 1000BASE-T, 100BASE-TX, 10BASE-T
IEEE Std 1588-2008 Precision Time Protocol
HD Audio High Definition Audio Specification Rev.1.0a
eSPI Intel Enhanced Serial Peripheral Interface Bus
Interface Base Specification Rev. 1.0
M.2 PCI Express M.2 Specification Revision 4.0
NVMe NVM Express 2.0 specification
PCI Express® PCI Express® Base Specification 3.1
PCI Express® Base Specification 4.0
SATA Serial ATA 3.0 & 3.1 Specification
TPM Trusted Platform Module 2.0
UEFI Unified Extensible Firmware Interface
UEFI Specification Version 2.9
UEFI Shell Specification Version 2.2
ACPI Specification Version 6.3
USB Universal Serial Bus 3.2 Specification Rev.1.0
Universal Serial Bus 4 Specification Version1.0
Type-C Cable and Connector Specification Rev. 2.1
Type-C Locking Connector Specification Rev. 1.0
Universal Serial Bus Power Delivery Specification Rev. 3.1
© EKF
Reference Documents
-6-
Origin
www.picmg.org
www.vesa.org
standards.ieee.org
www.intel.com
www.intel.com
www.pcisig.com
www.nvmexpress.org
www.pcisig.com
www.sata-io.org
www.trustedcomputinggroup.org
www.uefi.org
www.usb.org
