Front Panel Switches & Indicators
FPH Front Panel Handle integrated microswitch (red button)
Programmable function, power event button by default
GP General Purpose bicolour LED
HD LED indicating any activity on SATA ports
HT LED indicating CPU or voltage regulator high temperature (yellow)
PG Power Good/Board Healthy bicolour LED
RB System Reset Button (Option)
PG
Green/Red
OFF
OFF
OFF
GREEN
GREEN
YELLOW BLINK
RED
RED BLINK
© EKF
LED
GP
Green/Red Green
GREEN GREEN
GREEN
OFF GREEN
RED BLINK
X
X
X
X
HD
Sleep State S5 (Soft Off)
OFF Sleep State S4 (Suspend to Disk/Hibernate)
Sleep State S3 (Suspend to RAM/Standby)
X
X Board Healthy and in S0 State
X Front panel handle is unlocked
X Hardware Failure - Power Fault
X
-27-
Status
After Reset
Software Failure
