Page 1: Parts List
™ ReliaVac 12HP PARTS LIST Nilfi sk-Advance MODEL 56648071 11/04 revised 7/05 FORM NO. 56042457... - Page 3 04-11 TABLE OF CONTENTS 05-3 ReliaVac ™ 12HP DESCRIPTION Base Assembly ... 2-3 Handle Assembly ... 4-5 Wiring Diagram ... 5 Use the 8 digit numbers from the “Ref. No.” columns in this parts list. Specify the model and serial number of the machine. Use the space below to record the model and serial number for future reference.
-
Page 4: Base Assembly
BASE ASSEMBLY ReliaVac Rear R.H. Vac Motor mounting screw should be .625" long FORM NO. 56042457 ™ 12HP 18 18 Remaining 3 Vac Motor mounting screws should be .75" long 04-11 05-1... - Page 5 Power Cord Assembly (see #1 on page 5) 56648426 Light/Lens Kit 56630680 Asm, Headlamp Socket 56630722 Lamp, Headlight, 115V 56648413 Brush Strip Kit 56648415 Beater Bar Kit 56052964 Magnet, Permanent 56630325 Upright Vacuum Accessory Kit * = Not Shown ** = Not Included (optional) FORM NO. 56042457...
- Page 6 04-11 HANDLE ASSEMBLY 05-3 ReliaVac ™ 12HP FORM NO. 56042457...
-
Page 7: Handle Assembly
04-11 HANDLE ASSEMBLY 05-7 ReliaVac ™ 12HP Item Ref. No. Qty Description 56648417 Power Cord Assembly (see #23 on page 3) 56648421 Hook Assembly 56648424 Handle Assembly 56648423 Bag Assembly 56648429 Grip, Handle—Dark Gray 56035451 Asm, Bag Zip Gray TYT HD Com 56637120 A/R Disposable Paper Bag (pkg of 10) 56039515...
