Fancom VLR.6 Manual page 17

ALARM DIAGRAM WITH A SIMPLE ALARM UNIT
(all alarm contacts and min / max thermostats in series)
CLIMATE
Fancom
computer
Min.- / Max-
thermostat
0,8mm
Fancom advises you to install a min /
max thermostat in each CLIMATE
room / house and to connect them to
the alarm circuitry.
ALARM DIAGRAM WITH A MULTIPLE ALARM UNIT
WEIGHING
Fancom
computer
2x0,8mm
Fancom advises you to install a min /
max thermostat in each CLIMATE
room / house and to connect them to
the alarm circuitry.
FEEDING
Fancom
computer
alarm contact
0,8mm
0,8mm
12Vdc
(alarm per section)
FEEDING
Fancom
computer
alarm contact
Siren
12Vdc
WEIGHING
Fancom
computer
0,8mm
Fancom
single 0,8mm
alarm
unit
2x0,8mm
Siren
OTHER
Peripheral
equipment
Fancom
multiple
alarm
unit
2x0,8mm
COUNTING
Fancom
computer
0,8mm
COUNTING
Fancom
computer
min. / max.-
thermostat
OTHER
Peripheral
equipment
CLIMATE
Fancom
computer
