Fancom VLR.6 Manual page 16

ELECTRICAL DIAGRAM VLR.6
Knob
RD
-
GR
s
At 0-10V control
change around
BL
BL and RD.
+
L
L1
Control unit
N Z
L2 T2
L2 A2 L1
white
blue
man. aut.
orange
C2
U
T2
Update d.d. By / Ref Subject:
Connection VLR.6
1.
2.
Doc.no: 03.01.9723.02
3.
Scale: n.v.t.
4. Fancom bv.
5. agro computers
Control
10-0Vdc (or 0-10Vdc)
fuse
F1
A1
black
brown
man. aut.
red
C1
V
T1
Technical modifications reserved
Version:
Sheet: of
d.d: 10-06-97 File: Schema VLR.6
By: VJ / Ref: PRe Prog.: CANVAS 5
