  • Page 2 N.B.: The original, authentic version of this manual is the English version produced by Fancom B.V. or one of its daughter companies (referred to further as Fancom). Any modifications introduced to this manual by third parties have neither been checked nor approved by Fancom. Modifications are taken by Fancom to include translations into languages other than English and the insertion and/or deletion of text and/or illustrations to/from the original contents.

  • Page 3: Table Of Contents

    Table of contents General introduction ..........................1 Documentation with the control computer..................1 How to use this manual ........................1 Fancom Sales & Service Center ..................... 2 F-Central FarmManager™ ......................2 Explanation control functions ........................3 Ventilation ............................3 Heating ............................13 Cooling ............................
  • Page 4 Operation and safety instructions These subjects are covered in a separate manual. This manual also applies to other control computers in the Fancom F2000-line. Always read the safety instructions and warnings carefully before using the control computer. Always keep this manual close to the Lumina 35.

  • Page 5: Fancom Sales & Service Center

    For any questions and support, please contact the local Fancom Sales & Service Center. Virtually all Fancom equipment can be controlled and managed from a central location. This requires the F- Central FarmManager software package and a communication module. The screens in the control computers are...

  • Page 6: Explanation Control Functions

    Lumina 35 Explanation control functions Please refer to the user's manual for an explanation of the basic principles of climate management. This chapter describes the working of a number of specific control functions that the installer should set. Ventilation is used to create the most pleasant climate possible in the house. Ventilation also extracts harmful substances from the house and introduces fresh air into the house.
  • Page 7 Lumina 35 Explanation control functions Part of the ventilation demand can be met using natural ventilation. During natural ventilation the fans are off. The outside wind provides the air flow through the house. The entire combi-table is deactivated in the natural ventilation phase.

  • Page 8: Ventilation

    Lumina 35 Explanation control functions Transition Natural ventilation → Power ventilation (1) With falling temperatures the control computer switches over to low ventilation when the curtains are open minimum and the temperature falls below Natural start (1). The inlets for natural ventilation (curtains) are closed.
  • Page 9 Lumina 35 Explanation control functions The control computer can control controllable fans and extra fans. Controllable fans can be controlled by the control computer at a certain percentage. The control computer controls the fans from, for example, 30% to 100%. This enables the control computer to increase ventilation precisely up to the required level.
  • Page 10 Lumina 35 Explanation control functions Extra fans can only be switched on or off via a relay. They are usually used when the controllable fans are running at maximum or in combination with controllable fans to achieve a gradual increase in ventilation.
  • Page 11 Lumina 35 Explanation control functions The ventilation level is expressed as a percentage. Using this percentage the control computer can locate the required level of control of the fan(s) in the combi-table. Extra fans are shown in the combi-table as value ‘0’ (off) or ‘1’ (on).
  • Page 12 Lumina 35 Explanation control functions The settings that have to be made for the tunnel part (T-part) correspond broadly with the settings for the M/MT- part. Instead of the ventilation position in % you enter the offset temperature for the positions. At the first position this offset temperature is linked to start temperature ventilation + calculated bandwidth.
  • Page 13 Modulating control allows minimum ventilation to be achieved using, for example, a large fan. Fancom differentiates between the following types of modulating control: • Modulating control with fixed modulation times •...
  • Page 14 Lumina 35 Explanation control functions Linear controlled fans have a minimum ventilation level, for example 30%. This determines below what percentage the ventilation will modulate, and the ventilation level during modulating. If, for example, the calculated output of the linear part is 10%, ventilation will run for 10/30th of the cycle time at 30%, and not run for the rest of the time.
  • Page 15 Lumina 35 Explanation control functions In order to ventilate the right amount of air and to have a perfect air distribution, it is possible to ‘pulse’ the air to the middle of the house for a fixed amount of time and then wait until the fresh air is nicely spread over the birds.

  • Page 16: Heating

    Lumina 35 Explanation control functions The fans which must activate at a certain ventilation position have been set in the relay or combi-table. However, this means that the same fans will always be active. Using rotating the control computer will activate the number of assigned fans, but in a different sequence each time.
  • Page 17 Lumina 35 Explanation control functions The control computer activates heating if the house Setpoint – temperature drops below hysteresis. If the house temperature rises, the heating will stay on until the control value heating is reached. A set Repeat time can be used to prevent unnecessary activation/deactivation of the heating.

  • Page 18: Cooling

    Lumina 35 Explanation control functions P-control If the temperature is higher than the Control value, heating is on the minimum position. The minimum position is a user setting. If the temperature is between the Control value and Control value P-band, heating will be at a position between minimum and 100%, depending on the difference.

  • Page 19: Humidifying

    Lumina 35 Explanation control functions Cooling is modulating on, if the temperature is in the Hysteresis. The control computer calculates the modulation time based on the Repeat time. Example: Time modulating cooling control Inside Hysteresis the control computer controls the cooling for a part of the Repeat time.

  • Page 20: Humitemp

    Lumina 35 Explanation control functions HumiTemp = Humidification Temperature If HumiTemp is used, it will correct the measured average house temperature depending on the setpoint and the measured relative humidity (RH). If HumiTemp is not used, the ventilation is controlled based on the average house temperature.

  • Page 21: Optisec

    Lumina 35 Explanation control functions OptiSec = Optimum Setpoint Control The control computer uses a neutral zone, with minimum ventilation and no heating. This lowers energy costs. The neutral zone is the area between control value heating and start temperature ventilation. If OptiSec is not...

  • Page 22: Installing The Lumina 35

    Takes into account the following guidelines: Figure 8: required edge distances Never place the Lumina 35 in a place where the weather has direct influence (not in the sun, not in places where the temperature can rise sharply etc.). Never mount the Lumina 35 near water pipes, drainage pipes etc.

  • Page 23: Connect The Lumina 35

    Connect other (signal wires) to the Lumina 35, see chapter Technical specifications. Close the cover. Always use the cable gland when connecting the Lumina 35. Use the sealing discs supplied to seal off any unused cable glands. Use a sealant to seal all cable glands, after the computer has been connected, to prevent the entry of moisture, dust and/or aggressive gasses.
  • Page 24 Lumina 35 Installing the Lumina 35 The installer can configure the control computer using the installation menu. This menu also contains screens for standard system settings and diagnoses. To call up the installation menu: press the navigation keys UP and DOWN simultaneously for a few seconds.

  • Page 25: System

    Lumina 35 System Access the system menu by pressing the UP and DOWN navigation keys simultaneously for a few seconds. SYSTEM → → tab page SYSTEM SYSTEM Common Program version Readout of the program version Clock type Setting of the 12 or 24 hour time indication.

  • Page 26: System

    Lumina 35 System → → tab page SYSTEM SYSTEM Units Unit of measurement Setting to simultaneously set all units to METRIC or NON-METRIC. Use the + and – key on the alpha-numeric keyboard to change individual values. → → tab page...

  • Page 27: Sd Card Menu

    Lumina 35 System → → tab page SYSTEM SYSTEM Sharing Share animal data Setting for sending or receiving animal data. The control computers in the network can share data. In this way the animal data only has to be entered once, at the sender.

  • Page 28: Application

    Lumina 35 System Update FUNC Update FUNC loads an operating system (type .FIN) from the SD-card onto the control computer. Select the required file using the + en – keys on the alpha-numeric keyboard. Confirm using the ENTER key. Update HI Update HI (HI = Human Interface) loads an operating system (type .HIN) for the...

  • Page 29: Communication

    If there is no S2S communication, the Receive and Transmit counters should be set to 0. FNet is the Fancom Network. Several control computers can be linked via this network. FNet is also used to operate the connected control computers from a connected PC.

  • Page 30: Io Test

    Lumina 35 System Use the Input (I) and Output (O) test menu to set the control computer to test the communication channels. In the IO-test menu inputs can be readout and outputs controlled at system level → SYSTEM IO TEST The functions in the IO-test menu stop all the control actions of the control computer.

  • Page 31: House Setup

    Lumina 35 House setup This chapter explains all the options in the HOUSE SETUP menu. HOUSE SETUP select the parts of the control computer you intend to use. The control computer will only display data relevant to you in the screens. Parts not used, will not be shown. Most codes are self explanatory.
  • Page 32 Lumina 35 House setup → tab page HOUSE SETUP Combi M/MT-part Setting indicating if the controllable part of the ventilation control consists of linear controllable fans (LINEAR) or modulating on/off fans (RELAY). Analog extra additional Setting indicating the number of analog (linear controllable) fans that you want to activate as extra fans in the controllable part.
  • Page 33 Lumina 35 House setup warm climate table can be used to enable the tunnel inlets in minimum ventilation. By using this setting coolpads can be used earlier in the combi table to cool the air. This is energy efficient and will provide a more stable temperature for the animals.
  • Page 34 Lumina 35 House setup → tab page HOUSE SETUP User Apply temperature curve Setting indicating if the house temperature is to be controlled based on the curve. Apply ventilation curve Setting indicating if the minimum and maximum ventilation levels are to be controlled based on the curve.
  • Page 35 Lumina 35 House setup → tab page → ZOOM HOUSE SETUP User Age Factor Setting used to determine how much correction is permitted: • Early • Normal • Late Min Correctie Setting of the allowed maximum compensation below the average house temperature: •...

  • Page 36: Installer

    Lumina 35 Installer This chapter explains all the options in the INSTALLER menu. In the combi-table the relationship between ventilation and air inlets for the entire ventilation course is entered. For more information about the combi-table, see “Combi-table page 7”.
  • Page 37 Lumina 35 Installer Con. / Your entry depends on a system setting set by the installer: Con. Extra / Mod. % • LINEAR (Con. Enter the positions of the linear controllable fans. • Con. Extra (This column is only active if extra fans are used in the controllable part)
  • Page 38 Lumina 35 Installer → → → → tab page INSTALLER VENTILATION COMBI MTT M/MT-phase (min) Cap. Position % Setting of the ventilation percentage at which fans should activate/deactivate and air inlets open/close. The ventilation percentages must increase from the lowest to the highest position.
  • Page 39 Lumina 35 Installer → → → tab page INSTALLER VENTILATION SETTINGS M/MT-part Description Setting of the name of the function. Output address Setting of the analog output address. Analog type analog Setting indicating the analog control type Extra analog Setting of the analog output address.
  • Page 40 Lumina 35 Installer Modulating: FIXED TIME Modulate below % Setting of the ventilation percentage, below which the control computer will apply modulating control to the linearly controlled part. This applies to fans that cannot be controlled below this percentage. Linearly controllable fans usually have a minimum ventilation level.
  • Page 41 Lumina 35 Installer → → → tab page Relay. INSTALLER VENTILATION SETTINGS Rotation time Setting of the period after which the relays rotate. Output address Setting of the combi relay addresses. Rotate Setting indicating if fans, controlled by the combi-relays, rotate in a certain sequence.
  • Page 42 Lumina 35 Installer Pre-run time Setting of the time in which the air inlets go to the required position, before the fans activate. Setting indicating if these air inlets are to be included in modulating ventilation — if Link modulation modulating ventilation is used.

  • Page 43: Ventilation

    Lumina 35 Installer Position lee side Setting of the compass positions, which represent the lee side of the house. If the wind comes from this direction (positions) under wind side, the ventilation control may be influenced. Nat. vent. start/stop Setting of values between which ventilation is natural.
  • Page 44 Lumina 35 Installer → → tab page INSTALLER HEAT COOL HUM Heat Description Setting of the name of the function. Temp. Inputs Setting the addresses of the analog inputs. If the temperature sensors have not been assigned, the control computer will use the house temperature.
  • Page 45 Lumina 35 Installer Delay Setting of the Delay to minimise the influence of temperature fluctuations. The control computer only applies the OptiSec-correction, if the actual house temperature has fallen below the setpoint house temperature during the wait time. For example, set a wait time of 2 hours. The control computer will only increase the correction when the actual house temperature has been below the setpoint house temperature for an uninterrupted period of 2 hours.

  • Page 46: Clocks

    Lumina 35 Installer → → tab page INSTALLER HEAT COOL HUM Humid Description Setting of the name of the function. Output address Setting of the analog output address (choice LINEAR control) or relay output (choice RELAY control). Relay type Setting of the type of relay control (ON/OFF / Modulating).
  • Page 47 Lumina 35 Installer The water clock is used to control the water supply in the house. One water clock can be used per house. → → INSTALLER CLOCKS WATER Description Setting of the name of the function. Time clock type Setting indicating how the user can use the clock: •...
  • Page 48 Lumina 35 Installer Relay type Setting of the passive (not controlled) relay status. • N.O. (normally open) if it makes no contact. • N.C. (normally closed) if it makes contact. → → → tab page INSTALLER CLOCKS LIGHT Common Description Setting of the name of the function.

  • Page 49: Registration

    Lumina 35 Installer → → → tab page INSTALLER CLOCKS LIGHT Control Control on Setting of the way in which light is controlled. This option is only available if light measurement=YES has been selected at light clocks. • LUX: If you want to control the light using a light sensor, select LUX. The light clock will adjust the light intensity to the measured light intensity.

  • Page 50: Outside Climate

    Lumina 35 Installer Address Setting of the address of the digital input. Registration input Setting the type of measurement: • MANUALLY: Enables you to enter the amount of today manually. • SLOW PULSE: Measuring instruments with a maximum frequency of 20 pulses per second (20 Hz).
  • Page 51 (COMM). Only enter the address of the input if INT is selected. Input wind speed Setting of the address of the digital input. Type wind measure Setting of the type of anemometer used. Fancom uses the following types of weather meters: • GREEN_2P (default) •...

  • Page 52: Inside Climate

    Lumina 35 Installer → INSTALLER INSIDE CLIMATE Temp. inputs Setting of the addresses of the temperature inputs. Pressure input Setting the address of the analog input. Speed press. contr. Setting of the speed at which the control computer determines influences...

  • Page 53: External Alarm

    Lumina 35 External alarm The control computer has digital inputs to which external alarms can be connected. EXTERNAL ALARM Description Setting of the name of the function. Input address Setting of the address of the digital input. The readout of the input value is between brackets.

  • Page 54: Inputs And Outputs

    Lumina 35 Inputs and outputs When controls are assigned, the I/O settings are filled in automatically. When Fancom equipment is used these settings will normally ensure correct control. These settings can be adjusted using the zoom function ( ). The input and output settings can be readout, and changed in the INPUT / OUTPUT menu. However, we advise you not to make changes here but to do these changes in the setup screens.

  • Page 55: Analog Inputs

    Lumina 35 Inputs and outputs Analog inputs have the following settings: Input address The address of the analog input. Type Readout of the type of measurement being carried out: • NONE • TEMPERATURE • PRESSURE Pa • CO2 5000 PP •...
  • Page 56 Lumina 35 Inputs and outputs Max. buffer The control computer repeatedly determines the difference between the actual control value and the required setpoint. It places these difference values in a buffer, until the Max. buffer is reached. The adjustment to the setpoint is the average of the values in the buffer. The control...

  • Page 57: Digital Inputs

    Extra digital outputs (DO) Connection for optional relay (FRM.8 print). Communication I/O-Net for extra inputs and outputs using I/O-modules. FNet, Fancom network for intercommunication of control computers and PC connection. FRM.8 8 Digital outputs (relays) Relay 1, 3, 5, 7: make-and-break contact Max.
  • Page 58 Lumina 35 Technical specifications Touch screen HI mainboard LED strip FUNC (CPU) IOB.4 (I/O) FPD25 (Power supply) FRM.8 (Internal relay)
  • Page 59 Lumina 35 Technical specifications AI type Type analog input • Voltage measurement (U) • Resistance measurement (R) 4 Analog outputs 4 Analog inputs 4 Digital inputs Relay 4 Digital outputs (relays) 8 Extra digital outputs...
  • Page 60 The control computer and the second I/O network module require a terminal resistor. The first I/O network module is looped. This does not require a terminal resistor. The Fancom Greenlink cable (UTP 1x2x0.8mm, unshielded twisted pair) used to wire the FNET and I/O net. Maximum cable length = 1200 meters.

  • Page 61: Appendix: Ec Declaration Of Conformity

    Lumina 35 Appendix: EC declaration of conformity Manufacturer Fancom B.V. Address: Industrieterrein 34 Place: Panningen (the Netherlands) Hereby declares that: Lumina 35 Satisfies the conditions of: The Low Voltage Directive 2014/35/EU according to EN-61010 the EMC Guideline, directive 2014/30/EU Emission and immunity according to NEN-EN-IEC 61326...
