CellCom System Messages
The following messages are communicated to the DMP SCS-1R receiver to indicate CellCom status:
130 WARNING: Cell Communicator Bus Failed
COMMUNICATION SECURITY FEATURE
The communication on the bus between the panel and the cellular communicator has failed while no areas of
the system were armed. This message may originate from both the panel and the cellular communicator as both
monitor the bus. The restoral message is S132.
131 ALARM: Cell Communicator Bus Failed
SERVICE NOTIFICATION FEATURE
The communication on the bus between the panel and the cellular communicator has failed while any area of the
system was armed. This message may originate from both the panel and the cellular communicator as both monitor
the bus. The restoral message is S132.
132 Cell Communicator Bus Restored
SERVICE NOTIFICATION FEATURE
The communication on the bus between the panel and the cellular communicator has restored. Message is sent
from the panel to the receiver and is a restoral for S130 and S131.
133 WARNING: Cell Communicator DC Failed
SERVICE NOTIFICATION FEATURE
The panel has received a message from the cellular communicator that its input DC voltage is missing or low. The
cellular communicator is operating from its internal battery. The restoral message is S134.
134 Cell Communicator DC Restored
SERVICE NOTIFICATION FEATURE
The panel has received a message from the cellular communicator that its input DC voltage has restored. This
message is a restoral for S133.
135 WARNING: Cell Communicator Low Battery
SERVICE NOTIFICATION FEATURE
The panel has received a message from the cellular communicator that the cellular communicator's standby
battery is low or missing. The restoral message is S136.
136 Cell Communicator Battery Restored
SERVICE NOTIFICATION FEATURE
The panel has received a message from the cellular communicator that the cellular communicator's standby
battery has restored. This message restores S135.
137 WARNING: Cell Communicator Tamper
SECURITY FEATURE
The panel has received a message from the cellular communicator that the cellular communicator's built-in
tamper circuit was placed in an open condition while no areas of the system were armed. The restoral message is
S139.
138 ALARM: Cell Communicator Tamper
SECURITY FEATURE
The panel has received a message from the cellular communicator that the cellular communicator's built-in
tamper circuit was placed in an open condition while one or more areas of the system were armed. The restoral
message is S139.
139 Cell Communicator Tamper Restored
SECURITY FEATURE
The panel has received a message from the cellular communicator that the cellular communicator's built-in
tamper circuit was restored to a normal condition. This message is a restoral for S137 and S138.
All the messages above are communicated by the XR100/XR500 control panel except S130 and S131 Cell
Communicator Bus Fail which is sent by both the panel and CellCom. For complete information, refer to the Host
Communication Specification (LT-0086).
