Instruction Manual
2.5in SATA Hard Drive to 3.5in Drive Bay Mounting Kit
BRACKET25SAT
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
Packaging Contents
• 3.5" Mounting Bracket
• Data/Power Adapter Cable
• Screw Kit
Installation
WARNING! Computer equipment can be severely damaged by static
electricity. Be sure that you are properly grounded before opening
your computer case or touching your hard drive.
1. Connect the
SATA Data/Power Combination Cable to the SATA
power and data ports.
2. Make sure that your computer is turned off and that you are
grounded. Remove the cover from your PC.
3. Secure the hard drive to the bracket using the provided screws.
Insert the bracket into an open 3.5" drive bay and secure the
bracket to your computer case.
4. Connect the remaining ends of the SATA Data/Power
Combination cable to an LP4 power connector (provided by the
computer power supply) as well as to an available SATA Data
connector on the host computer motherboard.
For the most up-to-date information, please visit: www.startech.com
1
2
1. SATA Data/Power Combination Cable
2. 3.5" Drive Bracket
drive
*actual product may vary from photos
Manual Revision: 02/21/2012
