Advantech PCE-5B06-00A1E Startup Manual

PCE-5B06-00A1E Backplane: 6-slot BP for 6 slot
Chassis, 1 PICMIG 1.3, 4 PCIe
Startup Manual
Packing list
Before you begin installing your card, please make sure
that the following materials have been shipped:
• 2 Two Port USB Cable
• PCE-5B06-00A1E User Manual
1st.ED
• M4*6*0.7 Round Screws (15 pcs)
• 2 years quality warranty card
If any PCE-5B06-00A1E of these items are missing or
damaged, contact your distributor or sales representative
immediately.
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the PCE-5B06-00A1E series Rev. A1
Part No. 200K5B0610
Printed in China
Specifications
Standard Functions
• PICMIG 1.3 slots:
PCE-5B06-00 supports PCE-5xxx CPU boards
p/n: 1700002204
• PCIe slots:
p/n: 200K5B0610
PCE-5B06-00 supports one PCIe x 16 slot, four PCIe x 1
slot
p/n: 1939000410
• USB (2.0) support: Four USB 2.0 port pin headers
p/n: 2190000902
Mechanical and Environment
• Dimensions: 317.5 x 142.17 mm
• Power supply voltage: +12 V, +5 V, -12 V, -5 V, +3.3 V
+5VSBY, +3.3VSBY
• Power requirements: Refer to the CPU Board, add-on
Card & Peripherals
• Operating temperature: 0 ~ 60° C
• Weight: 0.3 kg (weight of board)
1st Edition
Feb. 2007
PCE-5B06-00A1E Startup Manual 1
