Florenza Bed
Assembly Instructions
6' SUPER KING
Dimensions
(5')
Length - 210cm
Width - 155cm
Height - 115cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
– Please keep for future reference
Dimensions
(6')
Length - 210cm
Width - 185cm
Height - 115cm
5' KING
162/2377
183/8594
Issue 1 - 23/10/13
Advertisement
Related Manuals for Argos Florenza 162/2377
Summary of Contents for Argos Florenza 162/2377
- Page 1 Florenza Bed Assembly Instructions 162/2377 – Please keep for future reference 183/8594 6' SUPER KING Dimensions Dimensions (5') (6') Length - 210cm Length - 210cm Width - 155cm Width - 185cm Height - 115cm Height - 115cm 5' KING Important –...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Make sure you have enough • Assemble on a soft level components and tools listed on space to layout the parts before surface to avoid damaging the pages 2 and 3.
-
Page 3: Components - Parts
Components - Parts If you have damaged or missing components, call the Customer Helpline: 08456 400800 Please check you have all the parts listed below Headboard panel (155 x 75cm - 5') (185 x 75cm - 6') 2 Headboard post x 2 8 Wooden slat x 28 Support leg x 2 (45 x Ø3.8cm) - Page 4 Components - Fittings If you have damaged or missing components, call the Customer Helpline: 08456 400800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 Assembly Instructions Step 1 Assembling posts Place headboard panel Back face down onto a clean flat surface. Note: Fixing holes for posts should be facing Secure headboard posts to headboard panel Front using fixings Step 2 Assembling side rails With help, assemble side rails headboard using fixings B C E...
- Page 6 Assembly Instructions Step 3 Assembling slat support frame Assemble end support to the underside of side rails using fixings Repeat for both ends. b: : Screw short studs into the underside of central support Screw support legs onto the short studs and tighten.
- Page 7 Assembly Instructions Step 4 Attaching slats Fit wooden slats into the side rails shown. Note: Plastic caps already pre-assembled onto one end of wood slats Fit wood slats into both sides of plastic cap , before pushing cap into central support Assembly is complete.
