Summary of Contents for Argos 166/6890
- Page 1 OI WOW Eclipse Tall Cabinet 166/6890 35cm 30cm 170cm Issue 1 - 10/10/13...
- Page 3 Components - Panels If you have damaged or missing components, call the Customer Helpline:08456 400800 Please check you have all the panels listed below Upper left side panel Upper back panel Upper right side panel Under back panel Under right side panel Under left side panel Top panel Bottom panel...
-
Page 4: Tools Required
Components - Fittings Please check you have all the fittings listed below Note:The quantities below are the correct amount to complete the assembly .In some cases more fittings may be supplied than are required. Φ4 x 12mm Screw x 35 Locking Pin x 32 Locking Nut x 40 Metal Support x 4... - Page 5 Assembly Instructions NOTE:2 peoples assembly required. This assembly will take about 1.5 hours more or less depending on your skills. Step 1 Assembling under side panel Screw locking pins into corner pieces as shown. Loosen straight hinge screw as shown to separate it into &...
- Page 6 Assembly Instructions Step 1 - continued Slide part Assembling under side panel Screw Front Screw pins into under side panel Fix part and make sure shorter part facing down, insert locking nuts into it,tighten locking nuts to secure. Insert locking pins into under side panels.
- Page 7 Assembly Instructions Step 2 Assembling legs Unlock metal leg by using screw driver as shown. Use Φ4 x 12mm screw to fix leg plate on bottom panel Screw bolt on the leg plate by hand by hand. Note: Not use screwdriver to tighten for this step,to avoid overtighten.
- Page 8 Assembly Instructions Step 4 Assembling upper unit a： Attach corner pieces to upper side panel and insert locking nuts into it,tighten locking nuts to secure. Screw locking pins into upper side panels. two screw hole back side b： Carefully attach upper side panels to top panel and shelves as shown,insert locking nuts...
- Page 9 Assembly Instructions Step 5 Assembling the unit Attach upper unit to under unit as shown,insert locking nuts into upper side panel and tighten it clockwise to secure. Step 6 Assembling back panel Φ3 x12mm screw to fix back panel to the unit, please make sure the hole on upper back panel match top panel.
- Page 10 Assembly Instructions Step 7 Step 7 Assembling door panel Attach door panel to the unit by fixing onto as shown ,adjust the door left or right ,up or down ,in or out if needed . Step 7 Step 8 Assembling drawer Use 30mm screw to fix drawer side panel...
- Page 11 Assembly Instructions Step 9 Assembling drawer Pull out the runner, alignment to the groove on the drawer, then insert the drawer to close first. Carefully pull drawer out. Screw bolt into holes as shown, try if drawer stopper function well.
- Page 12 After above assembly, please double check and make sure all screws are tightened before us. NOTE:If you have damaged or missing components, call the Customer Helpline:08456 400800 Argos LTD,489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW...
-
Page 13: A Guide To - Wall Mounting & Fixings
A Guide to - Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit.
