Camden -

Assembly Instructions -

Dimensions

Width - 116.5cm

Depth - 49.5cm

Height - 183.5cm

Important -

Please read these instructions fully before starting assembly

If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800

2 Drawer 3 Door Mirror Robe

Please keep for future reference

305/0772

305/0765

162/3204

MADE IN

BRITAIN

Issue 3 - 12/12/13

Need help?

Do you have a question about the Camden 305/0772 and is the answer not in the manual?

Questions and answers

Summary of Contents for Argos Camden 305/0772

Page 1 Camden - 2 Drawer 3 Door Mirror Robe Assembly Instructions - 305/0772 Please keep for future reference 305/0765 162/3204 Dimensions Width - 116.5cm Depth - 49.5cm MADE IN Height - 183.5cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 3 - 12/12/13...
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 76kgs. space to layout the parts before recommend the Please lift with care. starting.
Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below Plinth (D2012A) (1090 x 96mm) Mirror Door (D2018MA) (1345 x 358mm) Left Side Right Side Upright...
Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Prepare the 2 drawer fronts Screw 2 metal dowels into the holes shown on the back of each drawer front Note: Tighten metal dowels up fully against...
Page 6 Assembly Instructions Step 4 Fit the drawer base Slide the drawer base down the grooves in the drawer sides and down into the groove in the drawer front Step 5 Fit the drawer back Fit the drawer back between the drawer sides Make sure that the drawer base...
Page 7 Assembly Instructions Step 7 Fit the brace bars Turn the 2 drawer assemblies over and fit a brace bar to each one. Position the brace bar in the middle of the drawer base between the drawer front drawer back Once in position secure the brace bar with 2 screws...
Page 8 Assembly Instructions Step 9 Prepare the upright Tap 2 wooden dowels into the ends 10mm of the upright Note: Wooden dowels must not stick out from the edge by more than 10mm or they may damage other panels. Finished To fit the rail holder front edge screw through the top hole with screw...
Page 9 Assembly Instructions Step 10 Prepare the top Screw 4 small metal dowels into the holes on the top Screw 2 metal dowels into the holes on the top Note: Tighten metal dowels up fully against the panels. Finished front edge Step 11 Prepare the horizontal Insert 4 large locking...
Page 10 Assembly Instructions Step 12 Fit the upright to the Push the top onto the upright Use a screwdriver to tighten the 2 large locking nuts fitted to the upright Finished Note: Turn the large front edge Finished locking nuts as far as front edge they will go - more than 1/2 a turn.
Page 11 Assembly Instructions Step 15 screw screw screw Prepare the right side Fit the 2 runners to the right side The 1st screw uses the 2nd hole in from the front of the runner The 2nd and 3rd screw use the holes that line up with the other panel Finished holes.
Page 12 Assembly Instructions Step 16 Finished front edge Fit the small back rail to the right side Push the small back rail onto the right side Use a screwdriver to tighten the large locking fitted to the back Finished of the small back rail front edge Step 17 Fit the right side to...
Page 13 Assembly Instructions Step 18 Fit the double metal dowel Tap the double metal dowel through the upright and into the small back rail until it ‘’bottoms out’’. Step 19 Secure the small back rail to the upright Use a screwdriver to tighten the large locking fitted to the back of the small back rail...
Page 14 Assembly Instructions Step 20 Prepare the left side screw screw screw Fit the 2 runners to the left side The 1st screw uses the 2nd hole in from the Finished front of the runner front edge The 2nd and 3rd screw use the holes that line up with the other panel holes.
Page 15 Assembly Instructions Step 21 Plain chipboard surface Prepare the large Finished back rail front edge Insert 2 large locking nuts into the large back rail Tap 2 wooden dowels into the large back rail Step 22 Plain chipboard surface Prepare the 2 plinths Insert 2 large locking nuts into each of the...
Page 16 Assembly Instructions Step 24 Fit the left side to the assembly Push the left side onto the assembly as shown. Note: You will need to make sure that the 2 small metal dowels fitted to the top , slide into the top of the 2 hollow core locking nuts fitted to the left side...
Page 17 Assembly Instructions Step 25 Fit the back panels The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Square up the unit by making sure that measurement x to x equals y to y.
Page 18 Assembly Instructions Step 26 Fit the hanging rails and drawers Push hanging rails into the rail holders fitted to the side and upright panels. Slide the wheels of the runners fitted to the drawers, over the wheels of the runners fitted to the side panels and push the drawers into position.
Page 19 Assembly Instructions Step 28 IMPORTANT Drill 2 handle holes in each of the plain DO NOT drill into the Mirror Door. doors only Carefully choose which 2 holes you need to drill in each of the plain doors. Important: DO NOT drill into the mirror door.
Page 20 Assembly Instructions Step 29 Fit doors and handles 2 people are needed here Note: The easiest way to attach each door is to fit the top hinge first, then align and fit the other hinges. Push the hinge onto the front part of the hinge plate Keep the hinge FLAT against the hinge...
Page 21 Assembly Instructions Step 30 Adjust doors if needed Before adjusting the doors, use a spirit level to check the top (or base) of the unit is level, front-to-back and side- to-side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit level BEFORE making any adjustment to the hinges,...
Page 22 Assembly Instructions Step 31 Attach bracket to top To prevent possible overbalancing, we recommend that this unit is secured to a suitable 10-15mm wall by use of the bracket fitted to the top of the unit. Fixings are not supplied, as they will need to suit Top of Unit the wall type and the...
Page 23 KEEP THESE INSTRUCTIONS FOR FUTURE USE If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW...
Page 24 ALR2833...
