Safety; Safety Markings - Steelcase Collaborative Operating Instructions Manual

Dimensions (B-Free)
A
A Width mm
B Depth mm
C Height mm
Weight
Width (A) mm
4 FH Acoustic (min.) kg
4 FH Acoustic (max.) kg
5 FH Acoustic (min.) kg
5 FH Acoustic (max.) kg
Connection values
Connection values of the mo-
dule
Connection values of the lumi-
naire
Type plate and product identification (FrameFour)
116 1075 001 / 01 – 03/2018
14
B
1
C
B
2
1400 / 1600
209 (B ), 434 (B )
1 2
1915 (5FH)
1400 1600
85.4 94.8
90.4 100.6
99.9 110.9
104.9 116.7
240 V AC / 16 A
24 V DC
Type plate and product identification (B-Free)
The type plate of the module is located on the inside of the
power closet.
The type plate of the assembled desk is located on the under-
side of the desktop.

Safety

Safety markings

The safety markings for the module Collaborative and the as-
sembled desk are located on the underside of the desktop.
B
>
25mm
A
>
25mm
www.steelcase.com
Danger of crushing hands and fin-
gers
Danger of crushing feet and toes
Only adults may operate desk and
module.
