Linear Technology DC193 Demo Manual

Ltc1626 single-cell li-ion, high efficiency, step-down dc/dc

Advertisement

Quick Links

DESCRIPTIO
The DC193 demonstration circuit is a step-down (buck)
regulator using the LTC
Li-Ion battery pack. The output voltage is easily set to 2.5V
or 3.3V with a simple jumper selection. Other output
voltages can be programmed with an optional resistor.
The demo board highlights the capabilities of the LTC1626,
which is able to smoothly shift from a high efficiency
switch-mode DC/DC regulator to a low-dropout linear
regulator (i.e., 100% duty cycle) when the Li-Ion battery
voltage drops to near the output voltage. When the battery
voltage rises again, the LTC1626 smoothly shifts back to
a high efficiency DC/DC converter. At low load currents,
PERFORMANCE
PARAMETER
Input Voltage Range
Output Voltage
Typical Supply Current
TYPICAL PERFOR A CE CHARACTERISTICS A D BOARD PHOTO
Efficiency vs Load Current
100
95
90
85
80
75
70
0.01
Arrow.com.
Downloaded from
U
®
1626 operating from a single-cell
SUMM
ARY
CONDITION
Operating Input Voltage
Maximum Input Voltage
Set by Jumper, J1, in J1A Position
Set by Jumper, J1, in J1B Position
Set by Jumper, J1, in J1C Position and add Optional Adjust Resistor, R6
I
= 0mA, V
= 3.5V
OUT
IN
W
U
V
= 3.3V
IN
V
= 2.5V
OUT
0.10
OUTPUT CURRENT (A)
DC193 • TPC01
LTC1626 Single-Cell Li-Ion,
High Efficiency, Step-Down
the LTC1626 automatically switches to Burst Mode
operation to reduce switching losses and maintain high
operating efficiencies. Further, the LTC1626 draws a mere
0.5µA when in shutdown mode. A built-in 0.32Ω P-channel
switch allows up to 0.6A of output current and provides up
to 95% efficiency. Exclusive use of small surface mount
components results in a highly efficient application in a
very small board space.
Gerber files for this circuit board are available. Call the
LTC factory.
, LTC and LT are registered trademarks of Linear Technology Corporation.
Burst Mode is a trademark of Linear Technology Corporation.
1.00
DEMO MANUAL DC193
NO DESIGN SWITCHER
DC/DC Converter
U
TM
VALUE
2.5V to 6V
7V
2.5V ±0.06V
3.3V ±0.10V
2.5V to 5V
165µA
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the DC193 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Linear Technology DC193

  • Page 1 LTC factory. voltage rises again, the LTC1626 smoothly shifts back to a high efficiency DC/DC converter. At low load currents, , LTC and LT are registered trademarks of Linear Technology Corporation. Burst Mode is a trademark of Linear Technology Corporation. PERFORMANCE...
  • Page 2 270pF 100pF *MOVE JUMPER TO J1C AND ADD RESISTOR, R6, FOR V ADJUST R6 = 10k/[(V /1.25) – 1] DC193 • SCHEMATIC Figure 1. DC193 Schematic Diagram PERFORMANCE SUMM PARAMETER CONDITION VALUE Maximum Output Current 0.6A Typical Switch ON Resistance = 25°C, V...
  • Page 3: Parts List

    (847) 956-0666 LTC1626CS (408) 432-1900 QUICK START GUIDE The DC193 demonstration board is easy to set up to • The LB pin is the low-battery detector input pin. evaluate the performance of the LTC1626. Please follow Normally, its input comes from the input voltage, the procedure outlined below for proper operation.
  • Page 4 DEMO MANUAL DC193 NO DESIGN SWITCHER OPERATIO The circuit shown in Figure 2 operates from input voltages However, when the load is relatively light, the LTC1626 from 2.5V to 6V. The output voltage is either 2.5V, 3.3V or automatically switches to Burst Mode operation. In this adjustable between 2.5V and 5V, depending upon the...
  • Page 5: Low-Battery Detection

    DEMO MANUAL DC193 NO DESIGN SWITCHER OPERATIO LOW-BATTERY DETECTION The low-battery detector senses the input voltage through an external resistor divider. This divided voltage connects to the (–) input of a voltage comparator (LB ) and is compared to an internal 1.25V reference voltage. Neglect-...
  • Page 6 DEMO MANUAL DC193 NO DESIGN SWITCHER OPERATIO Any unshielded lead, such as a ground lead on a scope switch resistance is low and it is driven quickly. The only probe, acts as an antenna for the switching noise in the solution is to limit the rise time of the switch drive so that supply.
  • Page 7 Information furnished by Linear Technology Corporation is believed to be accurate and reliable. However, no responsibility is assumed for its use. Linear Technology Corporation makes no represen- tation that the interconnection of its circuits as described herein will not infringe on existing patent rights.
  • Page 8 6. SOLDER MASK: USE FILM PROVIDED, BLUE OR GREEN. 7. SCORING: dc193f LT/TP 0298 500 • PRINTED IN USA Linear Technology Corporation 1630 McCarthy Blvd., Milpitas, CA 95035-7417 (408) 432-1900 FAX: (408) 434-0507 TELEX: 499-3977 www.linear-tech.com © LINEAR TECHNOLOGY CORPORATION 1998 Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
