Capital B
100 - 200 - 300
Code / Codice
Power consumption
Consumo di energia
Power supply
Alimentazione elettrica
Inrush current / Corrente di spunto
Power factor / Fattore di potenza
Electrical class / Classe elettrica
Weight / Peso
Operating temperature
Temperatura di funzionamento
IP rating / Grado IP
IK rating / Grado IK
Dimensions / Dimensioni
Capital 100 B
282 mm
[11.1"]
Capital 300 B
474mm
[18.6"]
Griven S.r.l. - Via Bulgaria, 16
46042 Castel Goffredo
Mantova - Italy
User's Manual
Rev. 1.0
Date: 25/07/2022
Capital 100 B
AL5038
0.35A @ 230V / 77W max.
220-240VAC 50-60Hz (CE)
120 and 277VAC 50-60Hz (ETL)
27.5A@240VAC / 25°C
cos.φ= 0.97
5.1 Kg / 11.2 lb
82 mm
[3.2"]
105mm
[4.13"]
Tel. +39.0376.779483
E-mail: sales@griven.com
Web: www.griven.com
Capital 200 B
0.69A@230V / 148W
65A@240VAC / 25°C
cos.φ= 0.96
9.5 Kg / 20.9 lb
-40°C to +50°C ( -40°F to 122°F )
© Copyright Griven 2020 - GRIVEN S.r.l. is continuously
developing and improving all its products.
We reserve the right to change specifications without
prior notification
AL5036
1A @ 230V / 220W max.
100-277VAC 50-60Hz
I
IP67
IK09
Capital 200 B
460mm
[18.11"]
551175
Capital 300 B
AL5034
70A@240VAC / 25°C
cos.φ= 0.97
14.7 Kg / 32.4 lb
90mm
[3.54"]
