Capital B
600
Code / Codice
Power consumption
Consumo di energia
Power supply
Alimentazione elettrica
Inrush current / Corrente di spunto
Power factor / Fattore di potenza
Electrical class / Classe elettrica
Weight / Peso
Operating temperature
Temperatura di funzionamento
IP rating / Grado IP
IK rating / Grado IK
Dimensions - Dimensioni
Griven S.r.l. - Via Bulgaria, 16
46042 Castel Goffredo
Mantova - Italy
User's Manual
Rev.1.0
Date: 26/07/2022
2A @ 230V / 440W max. total (1A @ 230V / 220W each bank)
20 3/8"
517mm
Tel. +39.0376.779483
E-mail: sales@griven.com
Web: www.griven.com
Capital 600 B
AL5032
100-277VAC 50-60Hz
140A@240VAC / 25°C (70A @240VAC each bank)
cos.φ= 0.97
32.8 Kg / 72.3 lb
-40°C to +50°C ( -40°F to 122°F )
© Copyright Griven 2020 - GRIVEN S.r.l. is continuously
developing and improving all its products.
We reserve the right to change specifications without
prior notification
I
IP67
IK09
5 7/8"
150mm
551176
