Pin Plcc Package - Texas Instruments EUROTEXT CF70200 Manual

FN PLASTIC CHIP CARRIER
(20-terminal package used for illustration)
7
17
18
0.81 (0.032)
0.66 (0.026)
Typ.
0.53 (0.021)
0.33 (0.013)
17.40 (0.685) min
16.510 (0.650) min
1.22 (0.048)
1.35 (0.053)
x 45º
1.07 (0.0042) 1.19 (0.047))
6 1 40
39
29
28
1.53 (0.060) Min.
0.64 (0.025) Min.
DIMENSIONS IN MILLIMETRES (INCHES)
4.20 (0.165) min
2.29 (0.090)
x 45º
0.51 (0.020) R Max
3 Places
Seating Plane
(The lead contact points
are within 0.10 (0.004)
1.14 (0.045)
R. Typ.
min
0.64 (0.025)
14.99 (0.590) min
(at Seating Plane)
1.27 (0.050) T.P.
