28-Pin Plastic Dual-in-line Wide Body Package
Dimensions in millimetres (inches)
C L
C L
15.24 ±0.25
(0.600 ±0.010)
105°
90°
2.8 (0.110) NOM
2.0 (0.080) NOM
2.4 (0.093) R NOM
EITHER
INDEX
0.25 (0.010) NOM
0.51 (0.20)
5.08 (0.2)
MIN
MAX
SEATING PLANE
3.17 (0.125)
MIN
1.27 ±0.51
(0.100 ±0.01.)
28
15
14
1
36.6 (1.44) MAX
1.78 (0.070)
1.14 (0.045)
1.27 ±0.51
(0.050 ±0.020)
2.54 ±0.25
(0.100 ±0.010)
0.84 (0.033)
MIN
