Altronix HubWayD Series Installation Manual page 7

The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user
to the presence of an insulated DANGEROUS VOLTAGE within the product's enclosure that may be of
sufficient magnitude to constitute an electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of impor-
tant operating and maintenance (servicing) instructions in the literature accompanying the appliance.
1U EIA 19" Rack Mount Chassis Dimensions (H x W x D approximate):
16 15
1.625"(41.3mm)
Front
0.75"
(19.1mm)
HubWay8D / HubWay16D Installation Guide
CAUTION: To reduce the risk of electric shock do not open enclosure.
There are no user serviceable parts inside.
Refer servicing to qualified service personnel.
1.625" x 19.125" x 8.5" (41.3mm x 486mm x 216mm)
14 13 12 11 10
Top and Bottom
1 2 3 4 CH 1-4 5
+ DATA --
1-8
Fig. 5
(ON)
Illuminated master power disconnect circuit breaker:
• OFF position Circuit breaker tripped – Switch not illuminated.
• RESET (ON) position – Switch illuminated.
9 8 7
17.625" (447.7mm)
6 7 8 CH 5-8
28VAC
OFF
24VAC
19.125" (486mm)
6 5 4 3 2
Rear
9 10 11 12 CH 9-12 13 14
+ DATA --
9-16
1
AC POWER
15 16 CH 13-16
28VAC
OFF
24VAC
