Monitoring System Activity and Performance

Performance History at the HDSL2 Interface

Figure 17 is an example of a 31-day HDSL2 performance screen as viewed from the H2TU-C. The HDSL2
interface has 31-day, 48-hour, 25-hour, and current statistic screens for the H2TU-C.
describes the acronyms used in the performance history screens.
Monitor Performance
-----------------------------------------------------------------------------
Date CV
01/20 -
01/21 -
01/22 -
01/23 -
01/24 -
01/25 -
01/26 -
01/27 -
01/28 -
01/29 -
01/31 -
02/01 14
-----------------------------------------------------------------------------
Use <Space> to cycle through
choices and <Enter> to view
ID: xxxx--xxxx--xxxx--xxxx
Monitor Performance
-----------------------------------------------------------------------------
Time CV
*00:00 -
*01:00 -
*02:00 -
*03:00 -
*04:00 -
*05:00 -
*06:00 -
*07:00 -
*08:00 -
*09:00 -
*10:00 -
*11:00 -
-----------------------------------------------------------------------------
Use <Space> to cycle through
choices and <Enter> to view
ID: xxxx--xxxx--xxxx—-xxxx
32
Event Log Config
H2TU-C HDSL2 31 Day History (Page 1 of 3)
ES SES UAS
- - -
- - -
- - -
- - -
- - -
- - -
- - -
- - -
- - -
- - -
- - -
10 10 14
Press: (N)ext Page, (P)revious Page, C(l)ear History
Interface
Statistics :
02/01/2001 12:30:01
Figure 17. H2TU-C HDSL2 31-day Performance History
Event Log Config
H2TU-C HDSL2 48 Hour History (Page 1 of 4)
ES SES UAS
- - -
- - -
- - -
- - -
- - -
- - -
- - -
- - -
- - -
- - -
- - -
- - -
Press: (N)ext Page, (P)revious Page, C(l)ear History
Interface
Statistics :
02/01/2001 12:30:01
Figure 18. H2TU-C HDSL2 48-Hour Performance History
