On-Board Dip Switch S1; Dip Switch S1 - ADC HiGain H2TU-C-202 Manual

Front Panel
O - DIP S
N BOARD
The H2TU-C-202 circuit board has an 8-position DIP switch, S1 (see
are listed in Table 2.
DIP switch S1 is the only means by which the options it controls can be set. The maintenance
terminal screens showing these option settings are read-only.
label on outside
Table 2. Functions of DIP Switch S1 (default settings are in boldface type)
Left Side Options
Sets the Equalizer for 133 to 265 feet
Sets the Equalizer for 266 to 398 feet
Sets the Equalizer for 399 to 532 feet
Sets the Equalizer for 533 to 655 feet
Selects line code Alternate Mark Inversion (AMI)
Enables the Loopback Timeout (LBTO) to
120 minutes after initiation
Enables system response to DDS latching loopback
commands for Fractional T1 (FT1) loopback capability and
enables CP disconnect and trouble indication
Configures the system for local powering
(a) Only one of the DSX-1 line equalization switches (1 - 4) can be selected at a time. If more than one switch is enabled, the lowest value setting
has priority.
6
S1
WITCH
HiGain
HDSL2
L 3E
H
H 2
ALM
T
D
U
S
LOOP *
L
C
Status LEDs
2 2
0
2
LBK
DSX
D
S
X
1
IN
l
BRG
l
OUT
RS-232
DCE
Card handle
(CLEI code
of handle)
Figure 3. DIP Switch S1
February 28, 2001
Figure
List number
DS1 bridging jacks
Craft port
Switch
Number
(a)
1 Sets the Equalizer to 0
(a)
2 Sets the Equalizer to 0
(a)
3 Sets the Equalizer to 0
(a)
4 Sets the Equalizer to 0
5 Selects line code Bipolar with 8-zero Substitution
(B8ZS)
6 Disables 120 minute LBTO and replaces it with NONE,
no timeout
7 Disables system response to DDS latching loopback
commands for Fractional T1 (FT1) loopback capability
and disables CP disconnect and trouble indication
8 Configures the system for Span powering
LTPH-TP-1005-02, Issue 2
3). The functions of DIP switch S1

DIP switch S1

(located on
circuit board)
Right Side Options
H2TU-C-202 List 3E
