ADC HiGain H2TU-C-202 Manual page 25

LTPH-TP-1005-02, Issue 2
ADC Config
Selection
Screen Options
Line Power OFF
(a)
Feed
ON
Remote ENA
Provisioning
DIS
Bipolar Violation ENA
Transparency
See "Bipolar
DIS
Violation
Transparency
(BPVT) Option"
on page 19.
DS1 BER ENA
Threshold
DIS
See "DS1 BER
(DBER) Option"
on page 19.
HDSL2 BER 1E-6
Threshold
See "HDSL2 BER
1E-7
Threshold (HBER)
Option" on
NONE
page 18 and
"System Alarm
Output Pins" on
page 56.
Special Loopback GNLB
Mode
A2LB
A3LB
A4LB
SmartJack ENA
Loopback
DIS
Minor Alarm ENA
DIS
Network AIS CI
Pattern
AIS
H2TU-C-202 List 3E
Table 6. H2TU-C-202 ADC Config Screen Options
Description
Disables powering to the HDSL2 pair.
Keeps the HDSL2 line voltage at nominal -185 Vdc.
Enables remote provisioning.
Disables remote provisioning.
Enables BPVs and HDSL2 CRC errors at the DS1 input to be converted into DS1 BPVs
at the DS1 output at the distant end. This makes HiGain HDSL2 transparent to BPVs.
Disables BPV Transparency.
Enables the fixed 24-hour DS1 BER threshold.
Prevents the generation of a system alarm due to DS1 BER.
System alarm relay contact closes and the Status LED flashes red when the Block
-6
Error Rate exceeds 10
System alarm relay contact closes and the Status LED flashes red when BER exceeds
-7
10 .
Prevents generation of a system alarm due to BER.
Configures the HiGain HDSL2 system to respond to the generic inband loopback
codes.
Configures the HiGain HDSL2 system to respond to the inband loopback codes of the
Teltrend addressable repeater.
Configures the HiGain HDSL2 system to respond to the inband loopback codes of the
Wescom addressable repeater.
Configures the HiGain HDSL2 system to respond to the inband loopback codes of the
Wescom Mod 1 addressable repeater.
Enables the HiGain HDSL2 system to recognize all inband SmartJack (SMJK)
loopback commands.
Configures the HiGain HDSL2 system to ignore all inband SmartJack loopback
commands.
Enables the generation of the output alarm on pins 20 and 21 when a system alarm
condition occurs.
Disables the generation of the output alarm on pins 20 and 21 when a system alarm
condition occurs.
If ALMP is set to AIS, this option specifies which pattern is sent to the network when
a remote LOS or AIS occurs. When configured for CI, an AIS-CI pattern is sent to the
network. For priority resolution, see
When configured for AIS, an AIS pattern is sent to the network.
February 28, 2001
. (Block Error Rate is based on the definition of Bit Error Rate.)
Figure 28 on page
Provisioning
44.
Continued
17
