Provisioning
Table 5 describes the standard Config screen options.
options. Selections in bold type are the factory default settings.
Table 5. H2TU-C-202 List 3E Standard Config Screen Options
Standard Config
Selection
Screen Options
Loopback NONE
(a)
Timeout
120
Loop Attenuation 0 through
Threshold 40 dB
32 dB
Margin Threshold 0 to 15 dB
5 dB
DS1 Frame AUTO
Formatting
UNFR
DS1 Line Coding B8ZS
AMI
H2TU-C 0
(a)
Equalization
133
See "H2TU-C
266
Equalization
(EQL) Option." on
399
page 19.
533
H2TU-R Line
Buildout
0 dB
-7.5 dB
-15.0 dB
Alarm Pattern AIS
See "Alarm
Pattern (ALMP)
LOS
Option." on
page 19.
H2TU-R TLOS ENA
Loopback
DIS
Network AIS
Loopback Pattern
LOS
(a) This option is controlled through the DIP switch setting.
16
Table 6 on page 17
Description
Disables automatic time-out cancellation of all loopbacks.
Sets automatic cancellation of all loopbacks to 120 minutes after initiation.
Determines the maximum loop attenuation before an alarm is declared. Zero
disables the alarm. The loop attenuation threshold can only be set through the
HiGain maintenance screens.
Default value.
Determines the minimum allowable margin below which a system alarm can
occur. Zero disables the alarm. The Margin (Alarm) Threshold can only be set
through the HiGain maintenance screens.
Default value.
Configures the HiGain HDSL2 system to operate in an auto-framing (AUTO)
mode. It detects and locks to both SF or ESF DS1 frame patterns. Line and
path performance parameters are maintained and displayed. Unframed
payloads will cause the ES-P and SES-P counters to increment.
Configures the same as AUTO except unframed payloads do not cause the
ES-P and SES-P counters to increment.
Places both the H2TU-C and H2TU-R into their B8ZS modes.
Places both the H2TU-c and H2TU-R into their AMI modes.
Sets the Equalizer to DSX-1 for 0 to 132 feet.
Sets the Equalizer to DSX-1 for 133 to 265 feet.
Sets the Equalizer to DSX-1 for 266 to 398 feet.
Sets the Equalizer to DSX-1 for 399 to 532 feet.
Sets the Equalizer to DSX-1 for 533 to 655 feet.
Sets the DS1 receive level output toward the Customer Interface (CI). H2TU-R
Line Buildout can only be set through the maintenance screens.
Sets the DS1 RLBO level toward the CI to 0 dB.
Sets the DS1 RLBO level toward the CI to -7.5 dB.
Sets the DS1 RLBO level toward the CI to -15.0 dB.
Enables the HiGain HDSL2 system to output an AIS payload at its DS1 ports
for LOSW and DS1 LOS. For priority resolution, see
Enables the HiGain HDSL2 system to output an LOS condition at its DS1 ports
for LOSW and DS1 LOS.
Enables a logic loopback at the H2TU-R when an LOS occurs at its DS1 input,
if enabled at the H2TU-R. For priority resolution, see
Disables Transmit Loss of Signal (TLOS) logic loopback.
Enables the H2TU-R to transmit an AIS towards CI for any network loopback.
For priority resolution, see Figure 28 on page
Enables the H2TU-R to transmit an LOS towards CI for any network loopback.
February 28, 2001
LTPH-TP-1005-02, Issue 2
describes the ADC Config screen
Figure 28 on page
Figure 28 on page
44.
H2TU-C-202 List 3E
