To bring the carbon tower back in use, follow the start-up procedure in section 5.1: Start Up
6.

MAINTENANCE AND SERVICE

6.1 Maintenance and Service Information

6.1.1 Routine Maintenance

The service must be carried out only by a qualified technician.
Before any service is carried out, always verify that:
Users operating the machine must wear hearing and eye protection. Each employee must
select proper personal protection device(s) (PPD). Hearing protection such as earmuffs, ear
canal caps, or earplugs are required to prevent permanent hearing damage or loss.
DAILY
ANNUALLY
6.1.2 Activated Carbon Replacement
CAUTION: Activated carbon dust is considered a nuisance dust. Proper precautions should
be taken prior to replacing the activated carbon material in the tower. Please refer to the
Safety Data Sheet (SDS).
1.
2.
3.
container.
4.
Only use manufacturer supplied activated carbon, which is high quality, high capacity activat-
ed carbon designed and sized for the carbon tower.
5.
6.
carbon will pack tightly. Some settling may be required in order to fit the specified fill amount
into the tower. Tank sizes may be the same for multiple models so do not be concerned if the
tower is not entirely full.
7.
disposal methods and procedures. Consult the appropriate SDS and follow all applicable laws
and regulations regarding disposal.
CLEARPOINT V
15
+ The unit is depressurized and ensure the unit is isolated from the compressed air
system
+ Check the differential pressure of any installed pre and post filtration
+ Check that the tower pressure gauge reads full line pressure
+ Replace the pre and post filter elements
+ Check the air quality for oil aerosol and oil vapor content. Replace the activated
carbon material in the tower as necessary
Isolate and shut down the carbon tower (see sect. 5.2).
Place a suitable container at the edge of the drain port on the bottom of the tower.
Open the drain port on the bottom of the tower and catch the activated carbon in the
Refill the tower with the recommended type, size, and quantity of activated carbon.
Replace the drain port using thread sealant.
Carefully knock on the sides of the tower chamber while filling so that the activated
Activated carbon contaminated with oil or other substances may require different
Series Activated Carbon Tower
®
(Rev. D)
