PRODUCT NAME: Camile Desk
ITEM NUMBER: MO586
ASSEMBLED DIMENSIONS : 30"H x 52"W x 21"D
PRODUCTS ARE NOT INTENDED
FOR COMMERCIAL USE.
UPDATED: 10-27-2020
Prevent accidentally discarding small parts or
hardware. Retain all carton contents until assembly
and installation are complete.
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
MADE IN INDONESIA
Page 1 of 5
Advertisement
Table of Contents
Related Manuals for Ballard Designs Camile MO586
Summary of Contents for Ballard Designs Camile MO586
- Page 1 Customer Service: 800-367-2810 Online: www.ballarddesigns.com PRODUCT NAME: Camile Desk ITEM NUMBER: MO586 ASSEMBLED DIMENSIONS : 30”H x 52”W x 21”D Prevent accidentally discarding small parts or hardware. Retain all carton contents until assembly and installation are complete. PRODUCTS ARE NOT INTENDED MADE IN INDONESIA FOR COMMERCIAL USE.
- Page 2 Assemble in location for intended use. REQUIRED TOOLS: Ltr. Qty. Hardware Included Phillips Screwdriver, Allen Bolts Allen Wrench (included) 6 x 40mm -Two person assembly suggested. Lock Washers Remove all parts, hardware and Flat Washers protective packaging from carton 16 x 6 x 2mm and carefully arrange on a clean, Allen Wrench level, padded surface.
- Page 3 STEP 1: Remove SIDE DRAWERS by first fully opening and locating RELEASE LEVERS on metal glides. Press DOWN on RIGHT LEVER and pull UP on LEFT LEVER while gently pulling Drawer out. STEP 2: Invert Top (F) onto a level, padded surface and orient each Leg Assembly (G) as illustrated. Secure Assemblies to Top using Allen Bolt (A) with Lock Washer (B) and Flat Washer (C).
- Page 4 STEP 3: Turn Desk upright onto Legs then reinstall both Drawers by aligning metal glides and gently pushing drawer closed. NOTE: Drawer may need to be open/closed several times for glides to lock in place. LEVELERS: Desk is equipped with Rotary Levelers installed under each Leg. If necessary, Desk may be adjusted by carefully lifting applicable corner and turning Leveler clockwise/counterclockwise.
- Page 5 WALL ANCHORING HARDWARE (ANTI-TIP) Qty. Hardware Included Ltr. Small Screw (6 x WARNING Large Screw Tip-Over Hazard (6 x 1 Bracket Serious or fatal crushing injuries can occur from a furniture tip-over Prevent tipping accidents. Anchor your furniture. Retention Belt 1.
