PRODUCT NAME: Edith Desk with Hutch
ITEM NUMBER: MO606
ASSEMBLED DIMENSIONS : 40 3/4"H x 56 1/2"W x 27"D
PRODUCTS ARE NOT INTENDED
FOR COMMERCIAL USE.
UPDATED: 3-15-2021
Prevent accidentally discarding small parts or
hardware. Retain all carton contents until assembly
and installation are complete.
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
MADE IN CHINA
Page 1 of 6
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ballard Designs Edith Desk with Hutch MO606
Summary of Contents for Ballard Designs Edith Desk with Hutch MO606
- Page 1 Customer Service: 800-367-2810 Online: www.ballarddesigns.com PRODUCT NAME: Edith Desk with Hutch ITEM NUMBER: MO606 ASSEMBLED DIMENSIONS : 40 3/4”H x 56 1/2”W x 27”D Prevent accidentally discarding small parts or hardware. Retain all carton contents until assembly and installation are complete. PRODUCTS ARE NOT INTENDED MADE IN CHINA FOR COMMERCIAL USE.
- Page 2 Assemble in location for intended use. REQUIRED TOOLS: Ltr. Qty. Hardware Included Allen Wrench (included), Small Allen Bolts Phillips Screwdriver 1/4” x 5/8” -Two person assembly suggested. Large Allen Bolts 1/4” x 1” Remove all parts, hardware and Lock Washers protective packaging from carton and carefully arrange on a clean, Flat Washers...
- Page 3 Assemble in location for intended use. STEP 1: Orient Left Frame (I) and Right Frame (H) as illustrated with Connector Tabs on edge near floor then attach Front Frame Connector (K) to each side using Small Allen Bolt (A) with Lock Washer (D) and Flat Washer (D).
- Page 4 Assemble in location for intended use. STEP 3: Carefully orient Top (G) as illustrated with drawers fronts facing upward. Align holes in Top with those in Connector Tabs on upper edge of Frame Assembly. Attach using Small Allen Bolt (A) with Lock Washer (C) and Flat Washer (D).
- Page 5 Assemble in location for intended use. STEP 5: Orient Hutch (L) with Left Hutch Frame (M) and Right Hutch Frame (N) as illustrated. Align holes and attach using four Small Allen Bolts (A) with Lock Washer s(C) and Flat Washers (D). Fully tigthen using Allen Wrench (M).
- Page 6 ANCHORING HARDWARE (ANTI-TIP) Ltr. Qty. Hardware Included Large Screw WARNING Small Screw Tip-Over Hazard Serious or fatal crushing injuries can occur from a furniture tip-over Prevent tipping accidents. Anchor your furniture. Bracket Retention Belt 1. Locate and mark a Wall Stud behind Desk at location for installation. 2.
