Locating components in the vehicle

1- To gain access to the SLP connector, remove metal clip to remove the white plastic housing.
Steering Lock Connector
2. Remove white
1. Remove
plastic housing
metal clip
2- Move the white plastic housing over enough to access the SLP cnnector.
Steering Lock
connector
8
403.TL8 2.32 2015 Lexus NX 200t (Smart Key)
