Test Setup
Connectors Pins
J11
J12
J13
J14
8
UCD90240EVM-704 24-Rail Sequencer Development Board
Table 2. Connector Definition (continued)
Name
1 GPIO5
2 GPIO6
3 GPIO7
4 GPIO8
5 GPIO9
6 GPIO10
7 GPIO11
8 GPIO12
1
2
3
4
5 +3V3_USB
6 GND
7 PMB_CTRL
8 PMB_ALERT
9 PMB_SCL
10 PMB_SDA
1 JTAG_TMS
2
3 JTAG_TDI
4
5
6
7 JTAG_TDO
8 GND
9
10 GND
11 JTAG_TCK
12 GND
13
14
1 MON1
2 MON2
3 MON3
4 MON4
5 MON5
6 MON6
7 MON7
8 MON8
Copyright © 2015, Texas Instruments Incorporated
Description
General Purpose I/O
General Purpose I/O
General Purpose I/O
General Purpose I/O
General Purpose I/O
General Purpose I/O
General Purpose I/O
General Purpose I/O
No connection
No connection
No connection
No connection
3.3-V power provided by USB Interface Adapter EVM
PMBus GND
PMBus CONTROL line
PMBus ALERT# line
PMBus Clock
PMBus Data
JTAG TMS
JTAG nTRST (unused)
JTAG TDI
JTAG TDIS (unused)
JTAG VTRef (unused)
JTAG KEY
JTAG TDO
JTAG GND
JTAG RTCK (unused)
JTAG GND
JTAG TCK
JTAG GND
JTAG EMU0 (unused)
JTAG EMU1 (unused)
Analog monitor input
Analog monitor input
Analog monitor input
Analog monitor input
Analog monitor input
Analog monitor input
Analog monitor input
Analog monitor input
