Connectors Pins
J6
J7
J8
J9
J10
SLVUAF3A – March 2015 – Revised March 2015
Submit Documentation Feedback
Table 2. Connector Definition (continued)
Name
1 EN17
2 EN18
3 EN19
4 EN20
5 EN21
6 EN22
7 EN23
8 EN24
1 LGPO1
2 LGPO2
3 LGPO3
4 LGPO4
5 LGPO5
6 LGPO6
7 LGPO7
8 LGPO8
1 LGPO9
2 LGPO10
3 LGPO11
4 LGPO12
5 GPIO1
6 GPIO2
7 GPIO3
8 GPIO4
1 PMBUS_ADDR0
2 PMBUS_ADDR1
3 PMBUS_ADDR2
4 SYNC_CLOCK
5 GPIO21
6 GPIO22
7 GPIO23
8 GPIO24
1 GPIO13
2 GPIO14
3 GPIO15
4 GPIO16
5 GPIO17
6 GPIO18
7 GPIO19
8 GPIO20
Copyright © 2015, Texas Instruments Incorporated
Description
Rail enable output
Rail enable output
Rail enable output
Rail enable output
Rail enable output
Rail enable output
Rail enable output
Rail enable output
Logic GPO output
Logic GPO output
Logic GPO output
Logic GPO output
Logic GPO output
Logic GPO output
Logic GPO output
Logic GPO output
Logic GPO output
Logic GPO output
Logic GPO output
Logic GPO output
General Purpose I/O
General Purpose I/O
General Purpose I/O
General Purpose I/O
PMBus address pin
PMBus address pin
PMBus address pin
Sync Clock pin
General Purpose I/O
General Purpose I/O
General Purpose I/O
General Purpose I/O
General Purpose I/O
General Purpose I/O
General Purpose I/O
General Purpose I/O
General Purpose I/O
General Purpose I/O
General Purpose I/O
General Purpose I/O
