5.3

Main Menu

Function Display
Mode Switch [M]
Enter Switch [E]
Up Switch [▲] Previous Menu
Down Switch [▼] Next Menu
5100-XX First screen at power up: Model No.
VXX-XX-- Second screen at power up: Version No.
Third screen at start up, will remain for 60
STARTING
seconds
XXX PPM Normal condition - default display
Mode ALMRSET: Mode Function - Alarm Reset
Banner: "Press [E] to reset alarm"
RESET Alarm Reset
XXX PPM Default Display
Mode ALMRSET: Mode Function - Alarm Reset
Mode CALIB: Mode Function - Calibrate
Mode SETUP: Mode Function - Set up alarms, relays, etc.
Mode MAINT: Mode Function – Maintenance
Mode EXIT-? Exit Mode
Enter XXX PPM Apply Selected Mode (Exit)
XXX PPM Default Display (Once a minute the sensor displays module address)
Description
SMC 5100-XX-IT Toxic Gas Detector Module
Reference
Section 6.3 Calibration Gas Delivery
Methods
Section 5.4 Set-Up
Section 5.5 Maintenance Sub-Menu
5 Operation
25
