Removing the 700 Color Mobile Computer from
Portable Reader
4 Remove the two retaining screws.
5 Grasp the 700 Color Mobile Computer at the display end,
and simultaneously lift up (away from the Reader), then pull
forward.
Portable Reader LED Location and
Explanation
Portable Reader LED Explanation
LED
Indicates
1
PWR
2
HOST COMM
3
RF ON
4
TAG COMM
5
BATT
IP3 Intellitag Portable Reader (UHF) Quick Start Guide
Reader label
Meaning
+5 Power is On. Reader is ready.
Data communication with Host is active.
RF Power is On.
Valid tag transaction.
Battery condition (Low RED, Full GREEN,
more than 20% but less than 80% ORANGE).
LEDs position
(top to bottom)
1, 2, 3, 4, 5
5
