  • Page 1 IP 30 Handheld RFID Reader User’s Guide...
  • Page 2 Intermec Technolgies Corporation. Information and specifications contained in this document are subject to change without prior notice and do not represent a commitment on the part of Intermec Technologies Corporation. © 2008 by Intermec Technologies Corporation. All rights reserved.

  • Page 3: Document Change Record

    Document Change Record This page records changes to this document. The document was originally released as Revision 001. Version Number IP30 Handheld RFID Reader User’s Guide Date Description of Change 4/2008 Revised to include correct part numbers for the CK61 power supply.
  • Page 4 IP30 Handheld RFID Reader User’s Guide...

  • Page 5: Table Of Contents

    Charging and Installing the Battery ....6 Attaching the IP30 ........8 Establishing a Connection with the IP30 .
  • Page 6 Specifications IP30 Specifications ........28 RFID Specifications ....... . . 28 Port Pin Assignments .

  • Page 7: Before You Begin

    Global Services and Support Warranty Information To understand the warranty for your Intermec product, visit the Intermec web site at Returns and Repairs > Warranty. Disclaimer of warranties: The sample code included in this document is presented for reference only.

  • Page 8: Telephone Support

    This document is for the person who is responsible for installing, configuring, and maintaining the IP30. This document provides you with information about the features of the IP30, and how to install, configure, operate, maintain, and troubleshoot it. viii korlim@gw.idif.co.kr...

  • Page 9: Related Documents

    2 Click Support > Manuals. 3 In the Select a Product field, choose the product whose documentation you want to download. To order printed versions of the Intermec manuals, contact your local Intermec representative or distributor. Patent Information Product is covered by one or more of the following patents:...
  • Page 10 Before You Begin IP30 Handheld RFID Reader User’s Guide...

  • Page 11: Getting Started

    Getting Started Use this chapter to familiarize yourself with the IP30 Portable RFID Reader. This chapter covers these topics: • Introducing the IP30 Learning About the IP30 • • Charging and Installing the Battery • Attaching the IP30 • Establishing a Connection with the IP30...

  • Page 12: Introducing The Ip30

    IP30 RFID Handle • Battery Product Documentation • The IP30 for the CK61 Series Mobile Computer comes with mounting plates so that you will be able to attach the IP30 to your CK61 or CK61ex. IP30 Handheld RFID Reader User’s Guide...

  • Page 13: What You Need

    What You Need To use the IP30, you need these items: • CN3 or CK61 Series Mobile Computer A custom application to read and write tags. For help, see • “RFID Applications and the IP30” on page 16. You will also need to upgrade your Windows operating system and SmartSystems Platform Bundle (SSPB) before you can connect the IP30 to your mobile computer.

  • Page 14: Learning About The Ip30

    Chapter 1 — Getting Started Learning About the IP30 This section explains the LEDs and ports on the IP30. Understanding the LEDs The IP30 has five LEDs that show you the operating status of the reader. LED Icon Descriptions LED Icon LED Name...

  • Page 15: About The Intermec Ready-To-Work Indicator

    IP30 is ready to work, pull the trigger. Understanding the Ports The USB version of the IP30 for the CK61 has two ports located on the IP30 adapter. To access these ports, you must remove the port cover.

  • Page 16: Charging And Installing The Battery

    IP30 USB Adapter Port Descriptions Port Power COM 1 Charging and Installing the Battery To charge the IP30 battery, you need to have power supply (P/N 851-082-103), a country specific power cord, and one of these chargers: • AC6 2-Bay Charger (P/N 852-907-001) •...
  • Page 17 To install the battery 1 Insert the battery into the IP30. 2 Once the battery is in the IP30, push the battery release button and slide the battery in until the battery is secure. IP30 Handheld RFID Reader User’s Guide Chapter 1 —...

  • Page 18: Attaching The Ip30

    To attach the IP30 to the CN3 1 Remove the CN3 handstrap and insert it into the IP30 handle. 2 Insert the CN3 into the IP30 as shown in the illustration on the next page. IP30 Handheld RFID Reader User’s Guide...
  • Page 19 Chapter 1 — Getting Started 3 Lock the CN3 into place by lowering it into the IP30’s locking bracket. 4 If you are using the Bluetooth version of the IP30, go to page 12 to establish a connection between your mobile computer and the IP30.

  • Page 20: Attaching The Ip30 To The Ck61

    Attaching the IP30 to the CK61 This section explains how to attach the Bluetooth and USB versions of the IP30 to your CK61. Before you attach the IP30, make sure you are using the correct mounting plates. CK61 and CK61ex mounting plates Note: The illustrations in this section show the CK61 mounting plate.
  • Page 21 3 Lock the CK61 into place by lowering it into the IP30’s locking bracket. 4 If you are using the Bluetooth version of the IP30, go to page 12 computer and the IP30. IP30 Handheld RFID Reader User’s Guide to establish a connection between your mobile Chapter 1 —...

  • Page 22: Establishing A Connection With The Ip30

    Chapter 1 — Getting Started If you are using the USB version of the IP30, insert the IP30 USB adapter into the docking connector until it snaps into place. Once you have secured the USB adapter into place, you can configure your device.
  • Page 23 For Windows CE, select Start > Programs > Windows Explorer. The Windows Explorer screen appears. Go to Program Files > Intermec > Network and double-tap the BluetoothReaderWizard icon. 3 Tap Add Reader. The wizard advances to the next screen.
  • Page 24 8 Tap Next. The computer connects to the reader and displays the remote device information. 9 Tap Finish. 10 Refresh Intermec Settings to see the Bluetooth reader under RFID. You can now configure and modify your device. For help, see “Configuring RFID Settings”...

  • Page 25: Creating And Using Rfid Applications

    Creating and Using RFID Applications This chapter explains how you can use RFID applications for the IP30 and includes these topics: • RFID Applications and the IP30 • Creating Applications for the IP30 • Configuring RFID Settings • Configuring the BRI Server...

  • Page 26: Rfid Applications And The Ip30

    Software > Development Tools > Developer Resource Kits. Creating Applications for the IP30 You must create an application for the IP30 before it can read and write tags. Intermec recommends this general outline for developing your RFID application: •...

  • Page 27: Configuring Rfid Settings

    Configuring RFID Settings This section explains how you use Intermec Settings to change the settings for the RFID module in the IP30. As you install and test applications, you can configure the RFID settings for the best system performance.

  • Page 28: Configuring The Bri Server

    BRI server. For help, see the next section. To configure BRI server settings 1 For Windows Mobile, go to Intermec Settings by tapping on Start > Settings > System > Intermec Settings. The Intermec Settings window appears.
  • Page 29 For Windows CE, go to Intermec Settings by tapping on Start > Settings > Control Panel and double-tapping on the Intermec Settings icon. The Intermec Settings window appears. 2 Tap on RFID > Application Connection. The BRI application server settings appear.
  • Page 30 Chapter 2 — Creating and Using RFID Applications IP30 Handheld RFID Reader User’s Guide...

  • Page 31: Upgrading And Troubleshooting

    Upgrading and Troubleshooting This chapter includes information on upgrading the IP30 and includes these topics: • Upgrading Firmware • Troubleshooting the IP30 • Calling Intermec Product Support...

  • Page 32: Upgrading Firmware

    Chapter 3 — Upgrading and Troubleshooting Upgrading Firmware This section explains how to upgrade the IP30 firmware using your mobile computer. There are two ways to upgrade your IP30: You can upgrade your IP30 using a media card. • •...

  • Page 33: Troubleshooting The Ip30

    RFID system can be solved by carefully checking the RFID settings and changing them accordingly. For help, see “Configuring RFID Settings” on page 17. having trouble connecting your IP30, look at the on the next page for possible solutions. IP30 Handheld RFID Reader User’s Guide Chapter 3 —...
  • Page 34 IP30. • Check to see if the mobile computer is working properly. If the device is busy, the IP30 will not be able to work as well if there are too many applications running in the background. • Make sure that the battery is fully inserted into the handle.

  • Page 35: Problems With Connectivity

    Settings to it’s default value of 500. See the Intermec Computer Command Reference Manual (P/N 073529-xxx). 5 Check your IP30 battery to see if it still has power. 1 Make sure that you have secured the USB adapter to your mobile device.

  • Page 36: Calling Intermec Product Support

    What error message did you see? • Can you reproduce the problem? • What versions of the IP30 and RFID software are you using? For help viewing software versions, refer to the mobile computer user’s manual. When you have gathered this information, call Intermec Product Support at 1-800-755-5505.

  • Page 37: Specifications

    Specifications This appendix includes physical and electrical specifications for the IP30 and information about the port pin assignments.

  • Page 38: Ip30 Specifications

    ISO 18000-6B (Fairchild and Phillips) ISO 18000-6C Phillips v1.19 865-867 MHz, 869 MHz, or 915 MHz Maximum: 29 dBm Maximum: 23 dBm 182 cm (6 ft) 91 cm (3 ft) 121 cm (4 ft) 70 cm (2 ft) IP30 Handheld RFID Reader User’s Guide...

  • Page 39: Port Pin Assignments

    Port Pin Assignments This section describes the port pin assignments for the USB version of the IP30 for the CK61. Serial Port (COM1) Pin 9 Serial Port Pin Assignments Adapter Port Pin 1 Ground Adapter Port Pin Assignment IP30 Handheld RFID Reader User’s Guide...
  • Page 40 Appendix A — Specifications IP30 Handheld RFID Reader User’s Guide...
  • Page 42 Worldwide Headquarters 6001 36th Avenue West Everett, Washington 98203 U.S.A. tel 425.348.2600 fax 425.355.9551 www.intermec.com © 2008 Intermec Technologies Corporation. All rights reserved. IP30 Handheld RFID Reader User’s Guide *934-018-002* P/N 934-018-002...
