Summary of Contents for Intermec IP3 Intellitag
- Page 1 Quick Start Guide IP3 Intellitag Portable Reader (UHF)
-
Page 2: Packing List
Computer you need to load the Portable Reader CAB files onto your mobile computer. Do that by going to either of these two sources: S 700 Series Color Software Tools CD-ROM (p/n: 235-099-001) S Intellitag Developer’s CD (p/n: ITD001) IP3 Intellitag Portable Reader (UHF) Quick Start Guide... - Page 3 Note: DO NOT remove the IR reflector from the inside of the Portable Reader. This IR reflector aids in the communication of the IrDA signal between the Portable Reader and your Mobile Computer Gold IR Reflector DO NOT REMOVE IP3 Intellitag Portable Reader (UHF) Quick Start Guide...
- Page 4 Mobile Computer fully engaged into Portable Reader 3 Attach the two retaining screws. Ensure that they go straight into the mobile computer openings. Ensure retaining screws go straight into the slots on your mobile computer IP3 Intellitag Portable Reader (UHF) Quick Start Guide...
- Page 5 TAG COMM Valid tag transaction. BATT Battery condition (Low RED, Full GREEN, more than 20% but less than 80% ORANGE). IP3 Intellitag Portable Reader (UHF) Quick Start Guide LEDs position (top to bottom) 1, 2, 3, 4, 5 Reader label...
-
Page 6: Battery Installation And Removal
Battery tab 2 To remove the battery pack, push the battery release latch forward and remove the battery pack from the handle. Battery release latch IP3 Intellitag Portable Reader (UHF) Quick Start Guide Battery latch... - Page 7 3 Aim the Reader front at the ID Tag and squeeze the trigger. To obtain a good first time read, you need to be within three feet of the ID Tag. Reader front IP3 Intellitag Portable Reader (UHF) Quick Start Guide Trigger...
-
Page 8: Performance Specifications
1 w maximum Modulation Data Rates Environmental Specifications Temperature Operating Non-Operating Humidity Operating IP3 Intellitag Portable Reader (UHF) Quick Start Guide Spec Detail Frequency hopper 902-928 MHz Spec Detail minimum: 28.5 dBm typical: 29.5 dBm maximum: 30.0 dBm 99%, 40 dB on/off... -
Page 9: Overall Performance
FCC Part 15/Industry Canada ICES-003/CISPR Class B digital emissions Firmware Architecture Firmware Spec Detail Communicates in one mode: Application Peripheral Interface (API). Protocol/Compatibility ANSI NCITS 256.2000 for API, part 2, part 3-1. IP3 Intellitag Portable Reader (UHF) Quick Start Guide... -
Page 10: Global Services And Support
Global Services and Support Warranty Information To understand the warranty for your Intermec product, visit the Intermec web site at http://www.intermec.com and click Service & Support. The Intermec Global Sales & Service page appears. From the Service & Support menu, move your pointer over Support, and then click Warranty. -
Page 11: Telephone Support
Outside the U.S.A. and Canada, contact your local Intermec representative. To search for your local representative, from the Intermec web site, click Contact. IP3 Intellitag Portable Reader (UHF) Quick Start Guide In the U.S.A. - Page 12 6001 36th Avenue West Everett, Washington 98203 U.S.A. tel 425.348.2600 fax 425.355.9551 www.intermec.com E 2003 by Intermec Technologies Corporation. All rights reserved. IP3 Intellitag Portable Reader (UHF) Quick Start Guide August 2004 *962054065C* PN 962-054-065C IP3 Intellitag Portable Reader (UHF) Quick Start Guide...
