  • Page 1 Quick Start Guide IV6 Portable Reader...
  • Page 2 The information contained herein is proprietary and is provided solely for the purpose of allowing customers to operate and service Intermec-manufactured equipment and is not to be released, reproduced, or used for any other purpose without written permission of Intermec.
  • Page 3 5,280,159 5,504,485 5,673,037 5,763,867 5,828,318 5,828,693 5,942,987 5,995,019 6,122,329 6,172,596 6,280,544 6,286,762 6,360,208 6,384,712 6,486,769 6,501,807 6,645,327 6,677,852 6,816,063 IV6 Portable Reader 4,786,907 4,864,158 5,030,807 5,055,659 5,521,601 5,550,547 5,777,561 5,825,045 5,850,181 5,850,187 6,078,251 6,121,878 6,195,053 6,249,227 6,286,763 6,288,629 6,404,325 6,429,775...

  • Page 4: Packing List

    Microsoft Windows 98 or greater. This requires that Micro- soft Foundation be installed. Microsoft Foundation files can be located at http://www.microsoft.com. Once configured your IV6 Portable Reader also works in Windows 95. Compiler Support MS-DOS Development S Microsoft C compiler version 6.0 or greater S Borland C ++ compiler version 4.5x or greater...

  • Page 5: General Requirements

    Power Requirements Your IV6 Portable Reader is powered by an external DC power applied to a dedicated connector. The IV6 can only be used with UL approved limited power supply (p/n: 851-070-001)
  • Page 6 Reader. Auxiliary I/O connector Mounting bracket(s) one on each end IV6 Fixed Reader LED Explanation Meaning IRI (Blue) Off -Default state, unit is not ready to operate. Either because it does not have power or fails internal checks.

  • Page 7: Installation

    Installation Your IV6 Portable Reader can be installed using several options. For example, you can use band straps and mount it to the front of the fork lift, or to the side of the beams supporting the lift mechanism. The illustration below shows placement in some typical configurations.

  • Page 8: Environmental Specifications

    ETSI EN 300 019-1-4 Class 4E Quasi-Random Vibration Quasi-Random 20 G’s RMS for 4 hours. Shock 10g, 11ms, 1/2 Sin, (operating) Vibration 1.0 GRMS., 10 to 500 Hz, 3 axis (operating) Mechanical Shock 10 G, 11 msec, half sine pulse (operating) IV6 Portable Reader...
  • Page 9 915 MHz Antenna Specifications Frequency Range 902-928 MHz Impedance 50 ohms <1.3:1 VSWR Polarization Circular >30 dB Front-to-Back Ratio Maximum Input Power 1 watt at 50°C Far Field 3 dB Beam- 70° x 35° widths (Nominal) Mounting Hardware Band Clamps IV6 Portable Reader...

  • Page 10: General Purpose I/O

    General Purpose I/O Your IV6 Portable Reader supports a GPIO interface that con- sists of an industrial circular style female connector supporting the interface to industrial type controls. The interface includes: S Two optically isolated inputs. S Two optically isolated low voltage DC outputs.
  • Page 11 The interface includes access to 12 Volt power. This supply cur- rent limits at 0.25 Amps. This supply return is common to the unit input return power. The intended purpose of this supply is to power local loads such as relays or indicators. IV6 Portable Reader Cable Color Min. Typical Max.

  • Page 12: Serial Port

    Serial Port Your IV6 Portable Reader has a serial port used in conjunction with external DC power. The serial lines are connected through the circular GPIO/Power/Serial connector. The default data rate is 115.2k baud, with 8 data bits, no parity bit, 1 stop bit, no flow control.
  • Page 13 Config Timer Seconds If these parameter settings are acceptable you do not need to use the IV6 Configuration Utility. If you need to change one of these parameters you need to use the IV6 Configuration Utility to make that change.

  • Page 14: Troubleshooting

    2. Use the Bluetooth utilities in your PC to ensure that the reader has been discovered and that a Bluetooth connection has been established. 3. Ensure tag is within range of antenna. 4. Call Intermec Technical Support 1-800-755-5505 (option 2). IV6 Portable Reader...
  • Page 15 IV6 Portable Reader...
  • Page 16 Corporate Headquarters 6001 36th Avenue West Everett, Washington 98203 U.S.A. tel 425.348.2600 fax 425.355.9551 www.intermec.com e 2005 by Intermec Technologies Corporation. All rights reserved. IV6 Portable Reader Quick Start Guide *962-054-119A* P/N 962-054-119A...
